Effect of Laser Surface Modification and Tempering Process on Microstructure and Hardness Profiles of Roll Materials

Abstract:

Laser surface modification, using a continuous wave CO2 crosscurrent laser with generated beam power of 1 kW, was performed on the adamite steel, indefinite chilled cast iron and high speed steel rolls which were applied to the industries. Optical microscopy, scanning electron microscopy (SEM), energy-dispersive X-ray spectroscopy (EDS) and micro Vickers hardness test were applied to reveal the microstructural details and hardness profiles of the laser treated zone. The results indicate that, laser treated zones of three roll samples consist of melting zone, phase transformation zone and heat affected zone. After laser treatment, the melting zone have low hardness compared to the phase transformation zone, but after tempering at 540°C for 1 hr, the hardness at the melting zone dramatically increases, because of the formation of the fresh martensite from retained austenite. In contrast, the hardness at the phase transformation zone sharply decreases as fresh martensite changed to tempered martensite. There are many small and well distributed FeS and MnS inclusions in the melting zone at the three roll samples.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 1900-1905
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.1900
• Online since: August 2011
• Authors: Gen Zhe Huang, Zeng Hui Li, Jian Yin Tang
• Keywords: Hardness, Laser, Microstructure, Roll, Surface Modification

References

[1] Chen C H, Alstetter C J: Metall Trans, Vol. 15A (1984), p.719

[2] Trafford D, Bell N T, Megaw J H: Met Technol., Vol. 13 (1983), p.69

[3] Christodoulou G, Walker A, West D R F, et al.: Met Technol., Vol. 13(1983), p.215

[4] Abboud J H, West D R F: J Mater Sci Lett, Vol. 11 (1992), p.1322

[5] Zhengyang Li, Zhiyi Du, Bingyi Wang et al.: China International Steel Mill Rolls Conference, June 2-4, 2008, China Iron and Steel Association, p.350

[6] Rana J, Goswami G L, Jha S K, et al. ; Optics & Laser Technology, Vol. 39 (2007), p.385

[7] Gregson V G: Laser materials processing. Amsterdam: M. Bass (ch.4), (1983), p.209

[8] E.M. Breinan and B.H. Kear: Laser Materials Processing. Amsterdam: M. Bass (ch.5), (1983), p.236

[9] Yunxu Liu: Principle of Heat Treatment of Metal, China Machine Press, (1985), p.4

[10] Kac S, Kusinski J: Materials Chemistry and Physics, Vol. 81 (2003), p.510

[11] Colaco R, Vilar R: Wear, Vol. 258 (2005), p.225

[12] Daqing Zhu, Duluo Zuo, Shimin Li et al: Laser Technology, Vol.1 (2000), p.292 (in Chinese)

[13] Mazumder J: Laser heat treatment-the state of art. J. Metals, (1983), p.18

[14] Steen W M, Courtney C H G: Met Technol., Vol. 8 (1979), p.456
