An Intelligent Remote-Controlled LEGO ROBOT with TETRIX Metal Material Bricks

Abstract:

LEGO MINDSTORMS NXT is a popular system for learning robot science, but the way of remote control and carrying capacity is limited by connection wire length and plastics bricks. This study is to design an intelligent wireless controller that can connect with it. Connecting with touch sensor, accelerometer and gyroscope, the controller can sense the user motion in the three dimensions and then transmit sensor data to it through ZigBee network to drive it. Besides, the weak robot structure of LEGO bricks is strengthened by the TEERIX metal material bricks. The purpose of this research is to inspire the students’ interesting and enhance their applied ability of robot field.

• Periodical: Advanced Materials Research (Volume 321)
• Pages: 161-166
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.321.161
• Online since: August 2011
• Authors: Wen Ping Chen, Shan Chih Hsieh, Song Shyong Chen, Wei Ting Chang
• Keywords: LEGO Mindstorms NXT, Metal Material Bricks, Robot, ZigBee

References

[1] H. Yoshihiro, X. Han, and Junyu: Robot World NXC and NXT, Blue Ocean Culture (2009)

[2] Information on http://MINDSTORMS.lego.com/

[3] R. Schnitzler, J. Ballé, T. Herold, A. Telle, T.G. Noll, K. Hameyer, and T. Aach,: Generation NXT: MATLAB Meets LEGO Mindstorms—A Freshman Introduction Course Into Practical Engineering, IEEE Transactions on education Vol. 53, No. 2 (2010), pp.306-317

DOI: 10.1109/te.2009.2017272

[4] M.I.G Mota: Work In Progress-Using Lego MINDSTORMS and Robolab as A Mean To Lowering Dropout and Failure Rate In Programming Course, the 37th ASEE/IEEE Frontiers in Education Conference, Milwaukee (2007), pp.F4A-1-F4A-2

DOI: 10.1109/fie.2007.4418124

[5] A. Pásztor, T. Kovács and Z. Istenes: Swarm Intelligence Simulation with NXT Robots Using Piconet and Scatternet, the 5th International Symposium on Applied Computational Intelligence and Informatics (2009), pp.199-204

DOI: 10.1109/saci.2009.5136241

[6] G.C. Alfonso, G.de-G. Jesus, F.L. Jesus, M. Anthony, F. M. Victor, V.V. Fernando, and J. Klaus:Using LEGO Robots with Lab VIEW for a Summer School on Mechatronics, Proceedings of the 2009 IEEE International Conference on Mechatronics (2009), pp.1-6

[7] K.C.Y. Chin, S.M. Buhari and W.H Ong: Impact of LEGO Sensors in Remote Controlled Robot, International Conference on Robotics and Biomimetics Bangkok (2009), pp.1777-1782

DOI: 10.1109/robio.2009.4913271

[8] T. Karp, R. Gale, L.A. Lowe, V. Medina, and E. Beutlich: Generation NXT: Building Young Engineers with LEGOs, IEEE Transactions on education Vol. 53, No. 1 (2010), pp.80-87

DOI: 10.1109/te.2009.2024410

[9] Information on http://www.analog.com

[10] J.C. Hansen: LEGO MINDSTOMRS NXT POWER PROGRAMMING：ROBOTIC IN C SECOND EDITION, Independent Pub Group, (2009)
