Research on Inner Cooling Apparatus Sets in the Mold of 700mm×700mm Bloom

Abstract:

Based on the problems emerged from market, 700mm×700mm super-large billet has been advanced. This paper calculated the casting speed and the depth of liquid core according to empirical formula for 700mm×700mm super-large billet, based on calculate and feasibility analysis acquired the appropriate casting speed is 0.2 m/min. A new mold has been advance based on mold thermoanalysis that is complex mold. Theoretically analyzed the function of setting inner cooling and deflected SEN, indicate that complex mold can improve heat transfer efficiency and equiaxed crystal ratio, reducing center segregation; level rotary flow can uniform molten steel ingredient and growth of shell, reduce the impact depth, achieve the effect of E-EMS; calculation show that reduce the depth of liquid core by applying complex mold, finally, reduce infrastructure fee of caster.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 1623-1626
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.1623
• Online since: September 2011
• Authors: Ming Hua Bai, Jing Jing Liu, Jun Li Ge, Zhi Qiang Liu, Zhi Ming Zhang
• Keywords: Bloom Continuous Casting, Heat Transfer, Inner Cooling, Liquid Core Calculation

References

[1] J.X. Zhang: Continuous cast-steel directory (Metallurgical Industry Press, China 1990) p.127. (In Chinese).

[2] R.Y. Ying: Steelmaking, vol. (1996) No. 6, p.7.

[3] X.C. Cui, Y.J. Jin and Z Zhang: Journal of Iron and Steel Research, Vol. 19 (2007) No. 8, p.14.

[4] Chandra S: Iron making and Steel making, Vol. 20 (1993) No. 2, p.104.
