Cross-Sectional Configuration and its Combined Model of Yarns in Woven Fabric

Abstract:

CSCM in fabric is an important content of fabric geometry. Based on research work in the past, cross-sectional configuration of yarn in some real fabrics is observed. Several models can be used to describe it: round, ellipse and so on. Fabric with multiple weave-points below the same float can appear overlapping, staving and abnormal deformed yarns, especially serious in fabric with high density. So it’s unscientific to unify cross-sectional configuration to certain model, although there exist round, ellipse configuration in real fabric, triangle, cuneiform, sector are also observed in compacted fabric with multiple weave points. These models above are just examples only. In this case, it’s no meaningful to analyze the cross-section of mono-yarn. So combined CSCM is proposed to express yarn configuration in compacted fabric with multiple weave points.

• Periodical: Advanced Materials Research (Volumes 332-334)
• Pages: 1007-1010
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.332-334.1007
• Online since: September 2011
• Authors: Rang Tong Liu, Yan Fei Yang, Feng Hua Liu
• Keywords: Combined Cross-Sectional Configuration Model of Yarns in Woven Fabric, Cross-Sectional Configuration Model of Yarn (CSCM)

References

[1] Peirce F. T., The Geometry of Cloth Structure. J Tex. Inst.,1937, 28:45-96.

[2] Peirce F. T., Geometry Principles Applicable to the Design of Functional Fabrics. Textile Research Journal.1947,17:123-147.

DOI: 10.1177/004051754701700301

[3] A.Kemp. An extension of Peirce's Cloth Geometry to the Treatment of Non-circular Threads [J].Journal of Textile Institute,1958,(49):45.

DOI: 10.1080/19447025808660119

[4] Hamilton J. B.,A General System of Woven Fabric Geometry. J Tex. Inst., 1964,55:64-82.

[5] Hearle J. W. S., Shanahan W. J.. An energy method for calculations in fabric mechanics, Part I: principles of the method, J Textile Inst., 1978: 69,81-89

DOI: 10.1080/00405007808631425

[6] Shanahan W. J, Hearle J. W. S.. An energy method for calculations in fabric mechanics, Part II: examples of application of the method to woven fabrics, J Textile Inst., 1978: 69, 92.

DOI: 10.1080/00405007808631426

[7] JinLian Hu. Theories of woven Fabric Geometry[J].Textile Aisa, 1995,(1):56-60.

[8] Wang Yan-xin, Liu Rang-tong. Test Fabric Structure Parameters by Chip Technology, Cotton Textile Technology, 2006-11:12-15.
