The Finite Element Analysis of Sandwich Variable Cross-Section Plate Bending Performance

Abstract:

In order to investigate the bending performance of Continuous casting 945 steel sandwich board in cross plate, it is carried out the bending performance numerical simulation for Continuous casting 945steel ,find the largest stress zone in bottom plate when it is at the end of the Elastic stage; Find the most adverse regional、limit bearing capacity、stress-strain relationship and stress three-dimensions degree in the ultimate state. The most unfavorable area of board appeared in middle core board and mid-span junction of sandwich board. When applied 10mm and 90mm displacement, the most adverse regional appeared yield and destruction at first time. According to the stress three -dimensional degree can draw that tension board’s destruction form is stretch destroy in the most adverse regional. When applied limit displacement 90mm, the reaction force is 763.4KN in mid-span. The analysis results note that the most unfavorable area of continuous casting 945 steel sandwich board and destruction form, it has some practical significance for future sandwich board test.

• Periodical: Advanced Materials Research (Volumes 335-336)
• Pages: 659-662
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.335-336.659
• Online since: September 2011
• Authors: Yu Ping Sun, Chun Wei Min, Jin Li, Zun Li Teng
• Keywords: Bending Performance, Continuous Casting 945Steel, Sandwich Plate, Stress Three-Dimension Degree

References

[1] Tagarielli V L, Fleck N A, Deshpande V S. The Collapse Response of Sandwich Beams with Aluminum Face Sheets and a Metal Foam Core [J].Adv. Eng. Mater.2004, 6(6): p.440.

DOI: 10.1002/adem.200405154

[2] CAO J,AO H, K ARAF I LL IS A, et a l . Prediction of localized thinning in sheet metal using a general anisotropic yield criterion [ J ]. Int J Plasticity,2000,16：p.1105.

DOI: 10.1016/s0749-6419(99)00091-1

[3] Wei ShuXiu, Zhang Jiong. Casting 945 steel plate applied research [J]. Materials development and application，1997，9(5)：p.1. In Chinese.

[4] Zhang Min, Zu guoYin, YAO Guangchun. Bending properties of new aluminum foam sandwich plate [J]. Journal of Process Engineering，2007，7(3)：p.628. In Chinese.

[5] Cantwell W J, Compston P, Reyes G. The Fracture Properties of Novel Aluminum Foam Sandwich Structures[J].J. Mater. Sci. Lett.2000, 19(24): p.2205.

[6] Zhang Min, Zuguo Yin, YAO Guangchun. The preparation of Aluminum foam sandwich panels and its interface with Mechanism [J]. Functional Materials，2006, 37(2): p.281. In Chinese.

[7] McCormack T M, Miller R, Kesler O. Failure of Sandwich Beams with Metallic Foam Cores [J]. Int. J. Solids Struct.2001，38(28/29): p.4901.

DOI: 10.1016/s0020-7683(00)00327-9

[8] Contorno D, Filice L, Fratini L, et al. Forming of Aluminum Foam Sandwich Panels: Numerical Simulations and Experimental Tests [J]. J. Mater. Process. Technol.2006, 177(7): p.364.

DOI: 10.1016/j.jmatprotec.2006.04.028

[9] Li Lei,Feng Shun Shan,underwater explosion damage to the ship structure effect of Present Status and Prospects [J]. Ship Science and Technology，2008，30(3)：p.26.In Chinese.
