Researches of Warm Extrusion Forming Technology and Property on 42CrMo Steel Cutting Pick

Abstract:

Cutting pick is a kind of widely-used consumptive mining tool, however its body is easy to break in the mining producing process, the problem that pick body easy to break could be solved by using the warm extrusion forming techniques under the premise of without raising the material level. This paper mainly focuses on the structural characteristics and material technological properties of 42CrMo high-strength steel cutting pick body, and adopts the power balance principle got the approximation of the deforming force, and derived the approximate calculation formula of warm extrusion force for cutting pick body; and analyzed the temperature field, equivalent stress, strain field and metal’s flowing rate field of warm extrusion forming by adopting numerical simulation method, and verified the result with the experiment. The result shows that the material organization grains of cutting pick produced by the new technique could be refined; the pressing direction of cutting picks’ shape outline forms forging streamlines, the quality is good. In a word, this new technique could completely meet the requirement of cutting pick.

• Periodical: Advanced Materials Research (Volume 337)
• Pages: 536-541
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.337.536
• Online since: September 2011
• Authors: Chun Jian Su, Guang Heng Zhang, Jun Zhao
• Keywords: Cutting Pick, Precision Forming, Warm Extrusion

References

[1] Chunhua Wang, Baoheng Yao, Guixuan Li, etc. The Experiment Study on pick Cutting Coal Mining [J]. Mining & Processing Equipment, 2001,(12):6-8 In Chinese

[2] S.Fujikawa. Cold and warm-forging application in the automotive industry. J.Mater. Process.technol.1992,5:317-342

[3] Xiuke Du. Technical study of warm extruding precision forming mechanics model for cutting pick body of coal excavator [D]. [Master's thesis]. Yanshan University, 2007 In Chinese

[4] Hongqiang Cao, Hongbo Li, Jun Zhao. Research on warm extrusion process for rock drill body and other components [J]. Forging & Stamping Technology, 2005,(4):15-17 In Chinese

[5] Weibing Shi, Zili Liu, Zhengmao Sun. Analysis on warm extrusion processing parameters of spur gear and numerical simulation of die wear [J]. Forging & Stamping Technology, 2007,32(6):105-108 In Chinese

[6] Shidun Wu. Squeeze Theory [M]. National Defense Industry Press, 1994 In Chinese

[7] Jianxin Xie, Jing-an Liu. The theory and technology of metal extrusion [M]. Metallurgical Industry Press, 2001 In Chinese

[8] Chunjian Su, Xiuke Du. Quantitive analysis of warm extruding precision forming mechanics model for cutting pick body of coal excavator [J]. Forging & Stamping Technology, 2010,35 (2):89-93 In Chinese
