Photovoltaic Planning with Considering its Probabilistic Output in Distribution System

Abstract:

A large number of PVs can produce security and economic influence for distribution system, for its probabilistic and intermittent output. The solar radiation which PV component receives is easily influenced by clouds. The clearness index can reflect this. So a PV output stochastic model is built based on clearness index. In this paper the probabilistic output of PVs and loads are both considered and expressed by stochastic variables. A random expectation model has been built considering annual saved environment cost. The objective function is the minimum expected value of annual investment and operation cost. The operation constraints are to ensure the reliability and economy of power system. The solution algorithm is PSO combining with probabilistic power flow. Qualification rates of bus voltage and line power flow are examined after planning. At last the calculation example manifests this planning model can get good result under the condition of reflexing the probabilistic output of PVs and randomness of power loads.

• Periodical: Advanced Materials Research (Volumes 347-353)
• Pages: 481-486
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.347-353.481
• Online since: October 2011
• Authors: Li Fang Sun, Yu Qin Xu, Li Zhang, Kang Guo, Jian Fang Yue
• Keywords: Distribution Network Planning, Particle Swarm Optimization Algorithm (PSO), Probabilistic Power Flow, Random Expectation Model, Stochastic Model of Pvs’ Output

References

[1] Rongqiang Cui, Chunjiang Zhao, Dacheng Wu. Grid type solar photovoltaic power generation system. Beijing:Chemical Industry Press,2007(in Chinese).

[2] Ping Zhao, Yuting Yan. Research on Effect of Grid-connected photovoltaic System on Power Grid. Electrical Engineering. 2009,3:41~44(in Chinese).

[3] Wenjun Zhang, Haozhong Cheng, Zhengmin Cheng, et. Review of Power Distribution Network Planning. Power System Technology. 2008,20(5):16~23(in Chinese).

[4] Lixia Cai. A Study on Distribution Network Planning with Distributed Generation. Shandong University, 2009(in Chinese).

[5] Yibo Wang, Honghua Xu. Research of Capacity Limit of Grid-connected Photovoltaic Power Station on the Basis of Chance-constrained Programming. Proceedings of the CSEE. 2010,30(22):22~28(in Chinese).

[6] Jietan Zhang, Haozhong Cheng, Liangzhong Yao, et. Study on Siting and Sizing of Distributed Wind Generation. Proceedings of the CSEE. 2009,29(6):1~7(in Chinese).

[7] Yazhou Lei, Weisheng Wang, Shenghua Yin. Wind Power Penetration Limit Calculation Based on Chance Constrained Programming. Proceedings of the CSEE.2002,22(5):32~35(in Chinese).

[8] Hollands, K.G.T., Huget, R.G., 1983. A probability density function forthe clearness index, with applications. Journal of Solar Energy 30, 195~209.

DOI: 10.1016/0038-092x(83)90149-4

[9] Leiming Zhuang. The Optimization of Distributed Power Capacity in Urban Grid Planning. North China Electric Power University, 2010(in Chinese).

[10] Wei Xu. Research and analysis on the mathematic model of GCPV generation system. Power System Protection and Control. 2010,38(10):17~21(in Chinese).

[11] Charytoniuk V, Chen M S, Kotas P, Demand forecasting in power distribution system using nonparametric probability density estimation, IEEE Transactions on Power Systems, 1999, 14(4), 1200~1206.

DOI: 10.1109/59.801873

[12] Chengshan Wang, Haifeng Zheng, Yinghua Xie, et. Probabilistic Power Flow Containing Distributed Generation in Distribution System. Automation of Electric Power Systems. 2005,29(24):39~44(in Chinese).

[13] Pei Zhang, Stephen T. Lee. Probabilistic Load Flow Computation Using the Method of Combined Cumulants and Gram-Charlier Expansion. IEEE Transactions on Power Systems, 2004,19(1):676~682.

DOI: 10.1109/tpwrs.2003.818743
