The Multi-Humiture Monitoring System for General Storehouses

Abstract:

This paper discusses the design of the temperature and humidity monitoring system. It designs from software and hardware aspects in detail. The system included the three modules such as PC, FPGA and some peripheral circuit. Thereinto emphasis is laid on the introduction of hardware and software of communication interfaces of PC and FPGA. FPGA is core controller; PC is used to manage data acquisition and analysis. It introduces the data acquisition based on PXI bus and NI software LabVIEW. The system has the following advantages: its interface is friendly, its circuit is simple, its function is strong and its hardware system is integrated highly. The system realizes the monitoring the multi-humiture storehouses.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4194-4198
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4194
• Online since: November 2011
• Authors: Rong Fang Zong, Jing Ming Tian, Ji Shan Fan
• Keywords: Data Acquisition (DAQ), Field-Programmable Gate Array (FPGA), LabVIEW, PXI

References

[1] Xia Qian, Project of the MGIDS(Multi-channel Granary Temperature Detection System), Instrument Technology and Sensor[J], 2003(2): 39-42.

[2] Li Shanji, Piao Xiangfan, Design for wireless checkout system of cereal temperature, Microcomputer Information[J], 2005(10): 93-94, 105.

[3] Liu Duren, Han BaoJun. sensor principle and application of technology [M]. Shanxi: Xidian electronic technology University Press, (2003).

[4] Xu Zhijun, Xu Guanghui . FPGA/CPLD is developing and applies the [M]. Beijing: Electronics industry publishing house, (2002).

[5] Guoping Huo, Kun Wang, Qixin Ye LabVIEW7. 1 programme and virtual instrument design[M], tsinghua university Press, china , (2005).

[6] Lv Feilong, Chen Zhaozhang, The deign of temperature detecting system based on LabVIEW, Microcomputer Information[J], 2007(1): 170-171, 139.
