SINS Installation Error Calibration Based on Multi-Position Combinations

Abstract:

A new method is proposed to calibrate the installation errors of SINS. According to the method, the installation errors of the gyro and accelerometer can be calibrated simultaneously, which not depend on latitude, gravity, scale factor and earth's rotation rate. By the multi-position combinations, the installation errors of the gyro and accelerometer are modulated into the sine and cosine functions, which can be identified respectively based on the least squares. In order to verify the correctness of the theoretical analysis, the SINS is experimented by a three-axis turntable, and the installation errors of the gyro and accelerometer are identified respectively according to the proposed method. After the compensation of the installation error, the accuracy of the SINS is improved significantly.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4213-4220
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4213
• Online since: November 2011
• Authors: Zhen Huan Wang, Xi Jun Chen, Qing Shuang Zeng
• Keywords: Installation Error, Least Square (LS), SINS, Turntable

References

[1] Hall J J, Williams R L. Case study: inertil measurement unit calibration platform, Journal of Robotic Systems. 2000, 17(11), pp: 623–632.

DOI: 10.1002/1097-4563(200011)17:11<623::aid-rob4>3.0.co;2-7

[2] Eduardo Nebot, Hugh Durrant Whyte. Initial calibration and alignment of low–cost inertial navigation units for land vehicle applications, Journal of Robotic Systems, 1999, 16(2), pp: 81–92.

DOI: 10.1002/(sici)1097-4563(199902)16:2<81::aid-rob2>3.0.co;2-9

[3] Chen Bei ou, Sun Wensheng, Zhang Guihong. Srapdown unit (without orientation) six–position test calibration, Missile and Space Vehicle, 2001, 3(3), pp: 23–27.

[4] Fan Shenglin, Sun Yongrong, Yuan Xin. Calibration of gyro static drift parameters of strapdown system, Journal of Inertial Technology of China, 2000, 8(1), pp: 42–46.

[5] Liu Baiqi, Fang Jiancheng. Modified hybrid calibration method of IMU without orientation, Chinese Journal of Scientific Instrument, 2008, 29(6), pp: 1250–1254.

[6] Liu Baiqi, Fang Jiancheng. Novel field calibration through rotation in six–position for FOG–IMU, Opto–Electronic Engineering, 2008, 35(1), pp: 60–65.
