The Leak Detection System of Air-Conditioning Pipeline Based on LabVIEW

Abstract:

Air conditioning refrigerant leakage is often in the course of one fault occurs, the event of leakage, in a very short period of time cooling system will be unable to function properly. In order to realize the reign of air pipelines leak detection, this article is brought forth new ideas that pipe leak detection of air conditioning is achieved by the stress wave technology and by programming in the development environment of LabVIEW. Experimental results show that this new method is quick, accurate and reliable to detect and to locate the leak source occurred, the system measures the absolute positioning error is less than 0.3% and the relative error is better than 1.5%.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4235-4240
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4235
• Online since: November 2011
• Authors: Ya Ping Wang, Mu Cheng Zhu, Lin Tang, Shi Jie Liu
• Keywords: Air-Conditioning, LabVIEW, Leak Detection, Location, Pipeline, Stress Wave

References

[1] Li de-long, Seven methods of check the air conditioning system refrigerant leakage [J]. Light-duty vehicle technology. 2006(3). p.70~71 (In Chinese).

[2] Renai Mei, Le Jian, air-conditioning heat exchangers automatic helium leak detection device vacuum box [J]. Henan Mechanical College. 2005. 3. 13(2). 63~64(In Chinese).

[3] Yuan Zhi-guo, Yao Ming, Automotive air systems overhaul [J]. Practical automotive technology. 2008. 2. p.31~32(In Chinese).

[4] Wang Bang-feng, Chen Ren-wen, Leakage location system for oil pipeline based on stress wave detection[J]. Chinese Journal of Scientific Instrument，2007. 6. 28(6). p.1012~1017. (In Chinese).

[5] Su Wei-jun etc. Negative pressure wave positioning theory in the pipeline leak monitoring system[J]. Control & Automation. 2003. 19(3); p.1~6(In Chinese).

[6] Pan Wei, research on the natural gas pipeline leak automatically detection and location [D]. Lanzhou University of Science and Technology. 2003, p.16 ~ 17(In Chinese).

[7] Xiang Ke-feng. based on a number of LabVIEW Data Acquisition System Study [D]. Southwest University of Science and Technology. 2007, p.24 ~ 33(In Chinese).
