The Design of DC Motor Excitation Regulation System Based on DSP

Abstract:

The performance of excitation control system directly influences the motor’s movement characteristics. Currently, a lot of traditional excitation systems which use analog control circuits have the problem with their poor stability, aging components, slow response and great power lose. Aim to solve these problems, this text designs and implements a digital excitation regulation system based on DSP for DC motor. The regulation system takes full advantage of the powerful data processing ability of DSP chip for real-time rotational speed control of DC motor. This design is capable of ensuring the stability of the excitation system and improving the control efficiency, the circuit design is greatly simplified at the same time.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5123-5129
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5123
• Online since: November 2011
• Authors: Lv Yang, Jing Hong Zhao
• Keywords: DC Motor (DCM), Digital Signal Processor (DSP), Excitation System, PI, PWM

References

[1] Mai Yi, Electric Machine and Drag, South China University of Technology Press, Guangzhou, (2006).

[2] Chen Bo Shi, Automatic Control System of Electric Drive, China Machine Press, Beijing, (1997).

[3] Sun Bao Yuan, Yang Bao Qing, Sensor and Its Application Manual, China Machine Press, Beijing, (2004).

[4] Wang zhao an, Huang Jun, Power Electronic Technology, China Machine Press, Beijing, (2000).

[5] Liu He Ping, Yan Li Ping, Structure, Principle and Application of TMS320LF240X DSP, Beihang University Press, Beijing, (2002).

[6] Texas Instruments, TMS320c/F24X DSP Peripherals Reference Guide, Texas Instruments, (2003).

[7] David M Alter, Using PWM Output as a Digital-to-Analog Converter on a TMS320C240 DSP, Texas Instruments, (1998).

[8] Texas Instruments, TMS320LF240x/240xA Event Manager（EV)Reference Guide（Rev. C)，Texas Instruments, (2004).
