Pure Working Fluid Selection for the Organic Rankine Cycle in Waste Heat Recovery of Diesel Engine

Abstract:

According to the analysis of heat balance, about 1/3 of the fuel combustion heat is taken away into the ambience by exhaust gas of diesel engine. Depending on the characteristics of the diesel, this paper uses a special system to recover this waste heat, in which the organic Rankine cycle is combined with a single screw expander. The economy should be improved by using this system in the diesel. The model of this system is designed in Matlab combined with REFPROP. Using this way, the thermodynamic parameters should be calculated and the thermodynamic properties of this system with different working fluids should be analyzed. At last, R245fa, R245ca, R123 and R141b are selected as the alternative refrigerants used in this system.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6110-6115
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6110
• Online since: November 2011
• Authors: Hong Liang, Xing Liu, Hong Guang Zhang, Bin Liu, Yan Chen, Yu Ting Wu, Wei Wang
• Keywords: Diesel Engine, Organic Rankine Cycle (ORC), Waste Heat Recovery, Working Fluid

References

[1] Xiao Yongning, Pan Keyu, Han Guoyan, Thermol burthen and thermol better of engine, China machine press, 1988. (Chinese).

[2] Dong Guitian, Thermoelectric Generature of waste gas recovery for vehical engines, Beijing energy conservation, vol. 2, 1997, pp.7-9. (Chinese).

[3] Atan R, Heat Recovery Equipment (Generator) in An Automobile for An Absorption Air-Conditioning System, SAE Paper 980062, (1998).

DOI: 10.4271/980062

[4] Zeng Ke, Gao Ke, He Maogang, Huang Zuohua, Recent Development in the Research of Energy Utilization Efficiency for vehicle Engines, Vehicle engine, vol. 6, Dec. 2006, pp.1-4. (Chinese).

[5] Wang Wei, Wu Yuting, Ma Chongfang, Liu Linding, Prelimminary test research of the single screw expander, Solar energy, vol. 3, 2009, pp.30-32. (Chinese).

[6] D. Manolakos, G. Papadakis, S. Kyritsis, K. Bouzianas, Experimental evaluation of an autonomous low-temperature solar Rankine cycle system for reverse osmosis desalination, Desalination, vol. 203, 2007, pp.73-80.

DOI: 10.1016/j.desal.2006.04.018

[7] S. Quoilin, M. Orosz, V. Lemort, Modeling and experimental investigation of an organic rankine cycle using scroll expander for small solar applications, Proc. Eurosun Conf, (2008).

DOI: 10.1016/j.apenergy.2009.06.026

[8] Bertrand Fankam Tchanche, George Papadakis, Gregory Lambrinos, Antonios Frangoudakis, Fluid selection for a low-temperature solar organic Rankine cycle, Applied Thermal Engineering, vol. 29, 2009, p.2468~2476.

DOI: 10.1016/j.applthermaleng.2008.12.025

[9] Shi Dongxin, Refrigerant R11, Equipment for Geophysical Prospecting, vol. 6, 1988, pp.21-23. (Chinese).
