Synchronous Controller of LED Video Displays and LED Lighting Compatible

Abstract:

The development of a large display and can control a variety of compatible lighting control system, the system is suitable for wide range control distance. Can be widely used in modern college park, landscape building, business building and landscaping all buildings, publicity, service, advertising and other large screen and lighting systems. Using large-scale high-speed FPGA technology, Gigabit fiber communication technology, through a multi-level processing and protocol conversion, can be terminal for the different display mode (divided into static, 2 sweep, sweep 4, 8, sweep, sweep five kinds of 16), data in the order, alignment methods, control methods, the preparation of their own in the FPGA, the protocol conversion module, through the software are free to choose set the display terminal type, to achieve 16 control port can be controlled separately different types of display terminal. Control distance up to 5000 meters or more. Effectively address all the original control system can not be compatible, not centralized control, can not share resources and control of the key problems of distance is too short.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6959-6963
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6959
• Online since: November 2011
• Authors: Jian She Sun, Xiao Ning Feng, Yi Fei Sun, Hui Zhao
• Keywords: Compatible Control, LED Lighting, Main Controller, Sub-Controller, Video Display

References

[1] Ma Songde, Zhang Zhengyou. Computer Vision [M]. Second Edition, Beijing: Science Press, (2003).

[2] Ren Zhonghui, Ou Yangxi, Li Qibin. Multi-channel Data Varied-gain Acquisition System [J]. Micro Computer Information, 2010, (17)：132-133, 136.

[3] Li Gang, Fu Yuzhuo, Wang Shiming. A Real-time Video Processing System Based on FPGA and DSP[J]. Computer Simulation, 2005, 22(10): 254-256.

[4] Wu Zuoyong, Han Xinjie, Meng Xianyao. A Color Image Processing System based on ARM and FPGA [J]. Techniques of Automation and Applications, 2007, 26(4)：67-69.

[5] Lv Xizai, Huang Zhiping, Su Shaojing. Method of Clock Phase Correction in Wide-band Data Acquisition Based on FPGA [J]. Computer Measurement & Control, 2009, (11)：222-224.

[6] Yu Kunlin. Data Sampling and Processing System Based on DSP and FPGA Technology [J]. Changsha Aeronautical Vocational and Technical College Journal. 2004．（03）：38-40.
