Analysis and Experiment of the Eddy Current Losses for Canned Motor

Abstract:

Induced eddy currents in can cause loss when the canned motor runs, the loss make the motor`s temperature rise, directly affect the canned motor pump and the entire transmission system security. Empirical formula estimates eddy current losses which has a big error, it is difficult to meet the engineering requirements. For the canned motor with Hastelloy-C alloy or Sus316L cans, analyzed electromagnetic field and calculated can loss using a finite element method of Ansoft. The paper developed four prototypes, and obtained the experimental value of can loss via simple no-load experiment by the loss separation method. The results are compared with simulation value show that the accuracy of FEM is higher accurately than empirical formula; Analysis shows that dimension of a model and can material characteristic parameters such as the resistivity influence on the calculated error of FEM, the paper proposes to correct the error in the case of considering can material characteristic parameters.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 7521-7525
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.7521
• Online since: November 2011
• Authors: Yue Jun An, Guo Ming Liu, Hong Liang Wen, Wen Qiang Zhao, Li Ping Xue, Chun Ye Guo
• Keywords: Canned Motor, Eddy Current Losses, Finite Element Method (FEM), Loss Separation

References

[1] SUN Gui-Ying, ZOU Ji-Wu, LI Lian-Feng. Calculation of magnetic field and shield loss for shielded motor, [J]. JOURNAL OF HARBIN INSTITUTE OF TECHNOLOGY, 4, 1999, 31(4): 30-33.

[2] MA De-Xin. Brief Analysis on design characteristics of Canned induction Motors, [J]. Electrical Machinery Technology, 2001(1): 27-30.

[3] ZHANG Jian-Tao. Calculation of Eddy Current Losses and Analysis of Performance for Double Cans Composite Rotor Motor, [D]. Harbin University of Science and Technoligy, (2009).

[4] LIANG Yan-Ping, ZHANG Jian-Tao, SUO Wen-Xiu, ZHAO Bo, HU Gang. Eddy Current Losses Analysis of Double-cans Composite-rotor Motor, Proceedings of the CSEE, 0258-8013 (2009) 24-0078-06.

[5] JIANG Wei. The Analysis of Canned Motor with Variable Frequency Speed Regulation and Design of Control System, [D]. Huazhong University of Science & Technology, (2006).

[6] LIU Jian-Zhong. Computer-Aided Design of Canned Motors, [D]. Harbin University of Science and Technology, (2004).

[7] ZHANG Xiao-Chen, `Li Wei-Li, Cao Jun-Ci. Calculation and analysis for the can loss and performance of canned motors, [J]. Journal of Harbin Institute of Technology, 9, 2007, 39(9): 1422-1426.

[8] LI Shuai, PENG Guo-Ping, YU Zhen-min, et al. The application of Ansoft EM in motor Design, [J]. Micromotors, 2004(04): 52-54.

[9] YANG Yang. Finite element analysis of electromagnetic field of squirrel-cage asynchronous machine based on Ansoft [J]. Marine Electric & Electronic Engineering, 2007(4): 201-203.
