The Model Theory on Structural Mechanics of Cell Disruption Force in the Preparing Process of Superfine Wood-Flour with Cryptomeria fortunei

Abstract:

In the process of preparing superfine wood-flour with physical method, when the size of wood-flour particle reaches to the corresponding level, a single wood cell will be destroyed. In the process of analyzing micro-nano wood-flour’s cutting power, the process of cell disruption of the wood cell needs to be computed. Based on the relevant theory of finite element and structural mechanics, this article builds a structure mode of 12 lever hexagon truss model to simulate the cellular structure. There are 6 levers outside to simulate the cell and 6 levers inside to simulate the internal pressure. This establishes a single cell stress model to analyze its stress. It can be obtained that when the size of the force acting on the node reaches the unit force, the minimum tensile stress of the bar element is bigger than the macroscopic tensile strength of the wood. According to the structural characteristics of the cell wall, this paper compares the tensile stress along the grain of the bar element with the tradition cutting stress. Using tensile strength as the criteria to test the rupture failure of Cryptomeria fortunei cell, the wood cell’s disruption force can be concluded. When preparing superfine wood-flour with Cryptomeria fortunei as experimental raw materials, the calculated results of applying the traditional cutting theory to calculate the cutting force has proved the analysis structure of Cryptomeria cell micromechanics with the method of finite element and structural mechanics, so that it can be concluded that certain cutting force can make Cryptomeria fortunei cells disruption.

• Periodical: Advanced Materials Research (Volumes 393-395)
• Pages: 453-457
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.393-395.453
• Online since: November 2011
• Authors: Dong Xia Yang, Yan Ma, Chun Mei Yang
• Keywords: Cell Disruption, Structural Mechanics, Superfine Wood-Flour, Truss

References

[1] Yang Chunmei, Qi Yingjie and Sun Yonghua, in: Practical Analysis of Formation of the Sub-nanometer Cellulosine and Application Prospect, Journal of Northeast Forestry University, 63-65(2008), 36(10).

[2] Li Jian: Wood Science, Harbin, Northeast Forestry University Press, 1994, 12.

[3] Qi Yingjie, Yang Chunmei and Ma Yan, in: The Establishment and Simulation of the Simplified Model of External Outline of the Pine Cells, Scientia silvae sinicae, 93-95(2006), 42(9).

[4] Cheng Junqing, Yang Jiaju and Liu Peng, in: China Wood Chi, Peking, China Forestry Publishing House, 1992, 3.

[5] Piao Yongshou: Wood Cutting Science, Harbin, Northeast Forestry University Press, 1992, 7.

[6] Sun Yonghua, in: Research on Separation Process and Equipment of Drift Dynamics of the Sub-Nanometer Cellulosine, Harbin, Northeast Forestry University, 2009, 4.

[7] Wang Hui, Ma Yan and Yang Chunmei, in: Formation Process and Scale Calculation of the Sub-Nanometer Cellulosine, Wood Processing Machinery, 11-14(2005), 6.

[8] Jiao Qunying, Su Zhixiao, in: The Permanence and Achieve Conditions of the Plant Cell Area in Two-Dimensional Mechanical Model, Journal of Xiangtan Normal University, 87-91(2003), 25(1).

[9] Ruan Xigen, Yu Guanxia, in: Wood Physics, Peking, China Forestry Publishing House, 2005, 8.

[10] Yu Yan, Jiang Zehui and Ren Haiqing, in: Progress Review in Cell Wall Mechanics of the Tracheid, Scientia Silvae Sinicae, 133-139(2003), 39(5).

[11] Zhao Jingwen, Wang Hongyu, in: Structure Finite Element Analysis, Peking, Science Press, 2004, 4.

[12] Wang Shizhong: Structural Mechanics and Finite Element Method, Harbin, Harbin Institute of Technology Press, 2003, 4.
