A Pseudo Inverse Approach with Kinematically Admissible Intermediate Configurations for the Axi-Symmetrical Cold Forging Modelling

Abstract:

A simplified method called “Pseudo Inverse Approach” (PIA) has been developed for the axi-symmetrical cold forging modeling in this paper. The traditional “Inverse Approach” (IA) based on the assumptions of the proportional loading and simplified tool actions may quickly give a fairly good strain distribution, but poor stress estimation. Meanwhile the PIA proposed in this paper not only keeps the advantages of the Inverse Approach but also gives good stress estimation by taking into account the loading history. To fulfill this aim, some kinematically admissible intermediate configurations represented by the free surface are used to consider the deformation paths without classical contact treatment. A new direct algorithm of plasticity integration has been used by using the notion of equivalent stress and the tensile curve, leading to a very fast and robust plastic integration procedure. An axi-symmetrical forging has been taken as an example to validate the PIA.

• Periodical: Advanced Materials Research (Volumes 399-401)
• Pages: 1832-1837
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.399-401.1832
• Online since: November 2011
• Authors: Ali Halouani, Yu Ming Li, Boussad Abbès, Ying Qiao Guo
• Keywords: Cold Forging, Direct Algorithm of Plasticity Integration, Large Strain, Pseudo Inverse Approach

References

[1] C. Bohatier, J. L. Chenot, "Finite element formulation for non steady state viscoplastic deformation", Int. J. Meth. Eng., vol. 21, 1985, pp.1697-1708.

DOI: 10.1002/nme.1620210911

[2] S. M. Hwang and S. Kobayashi, "Preform design in plane-strain rolling by the finite element method", Int. J. Mach. Tool Des. Res. 24, 253-266, 1984.

DOI: 10.1016/0020-7357(84)90060-x

[3] T. Altan, G. Ngaile, G. Shen, Cold and hot forging – Fundamentals and Applications, ASM International Materials Park, Ohio, 2007.

DOI: 10.31399/asm.tb.chffa.9781627083003

[4] L. Fourment, S.H. Chung, "Direct and adjoint differentiation methods for shape optimization in non-steady forming application", European Conference on Computational Mechanics, Cracow, 2001.

[5] L. Fourment, T. Balan, Chenot J.L. "Optimal design for non-steady-state metal forming processes", Int. J. for Num. Meth. In Eng., Vol. 39, pp.51-65, 1996.

DOI: 10.1002/(sici)1097-0207(19960115)39:1<51::aid-nme845>3.0.co;2-#

[6] A. Halouani, Y.M. Li, B. Abbès, Y.Q. Guo. Simulation of axi-symmetrical forging process by Inverse Approach, Materials Science Forum Vols. 675-677 (2011) pp.1007-1010.

DOI: 10.4028/www.scientific.net/msf.675-677.1007

[7] A. Halouani, Y.M. Li, B. Abbès, Y.Q. Guo. "An Axisymmetric Inverse Approach for Cold Forging Modelling", "Engineering Letters, Vol. 18, Issue 4, pp.376-383, 2010.

[8] W. Gati, Y.Q. Guo, H. Naceur, J.L. Batoz, "Approche pseudo inverse pour estimation des contraintes dans les pièces embouties axisymétriques", Revue Européenne des Eléments Finis, Vol. 12, n° 7-8, pp.863-886, 2003.

DOI: 10.3166/reef.12.863-886

[9] Y.Q. Guo, J.L. Batoz, J.M. Detraux, P. Duroux, "Finite element procedures for strain estimations of sheet metal forming parts", Int. J. for Num. Methods in Eng., Vol. 30, pp.1385-1401, 1990.

DOI: 10.1002/nme.1620300804

[10] Y. Q. Guo, Y. M. Li, F. Bogard, K. Debray, "An efficient pseudo-inverse approach for damage modelling in the sheet forming process", Journal of Materials Processing Technology, Volume 151, Issues 1-3, pp.88-97, 2004.

DOI: 10.1016/j.jmatprotec.2004.04.105

[11] J.C. Simo, R.L. Taylor, "A return mapping algorithm for plane stress elastoplasticity", Int. J. Numer. Meth. Eng. 22 (1986) 649–670.

DOI: 10.1002/nme.1620220310
