Numerical Study of Large Defection of Functionally Graded Beam with Geometry Nonlinearity

Abstract:

The equation of large deflection of functionally graded beam subjected to arbitrary loading condition is derived. In this work assumed that the elastic modulus varies by power function in longitudinal direction. The nonlinear derived equation has not exact solution so shooting method has been proposed to solve the nonlinear equation of large deflection. Results of shooting method are validated with finite element solutions. The method will be useful toward the design of compliant mechanisms driven by smart actuators. Finally the effect of different elastic modulus functions and loading conditions are investigated and discussed.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 4226-4230
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.4226
• Online since: November 2011
• Authors: A. Soleimani, M. Saadatfar
• Keywords: Cantilever Beam, FGM, Large Deflection, Nonlinear, Shooting Method, Smart Materials

References

[1] K.E. Bisshop, D.C. Drucker, Q. Appl. Math., Vol. 3 (1945), p.272.

[2] L.L. Howell, A. Midha, ASME J. Mech. Des., Vol. 117 (1995), p.156.

[3] A. Saxena, S.N. Kramer, ASME J. Mech. Des., Vol. 120 (1998), p.392.

[4] C. Kimball, L. -W. Tsai, ASME J. Mech. Des., Vol. 124 (2002), p.223.

[5] A. Banerjee, B. Bhattacharya, A.K. Mallik, Int. J. Nonlin. Mech., Vol. 43 (2008), p.366.

[6] S. Suresh and A. Mortensen, Fundamentals of functionally graded materials, IOM Comm., (1998).

[7] B.V. SAnkar, Compos. Sci. Technol., Vol. 61 (2001), p.689.
