Design and Implementation of PoE System Compliant with IEEE802.3af

Abstract:

This paper introduces the principle and method of PoE,and adopts LTC4263 and LTC4257 to design the system of PoE compliant whit IEEE802.3af, and realize the circuit. The design can provide DC for low power dissipation LXI、IP phone、AP、IPCAM and some terminals base on ethernet, when they are transfeting the data signal. As adopted double power supply, it can improve the transmission current, to improve output power, can make the capacity of electric power supply of PoE move higher, and can be power supply mode of general-purpose equipment.
