The Innovative Design of Airliner Front Landing Gear Mechanism

Abstract:

On the basis of the existing mechanism, we can induce the topological structure of the original mechanism. By using the number synthesis of mechanism, we can find the link assortment which can satisfy topological structure of the original mechanism. By using permutation, we can obtain the generalized kinematic chains. According to the special design constraints, after appointing each link and kinematic pair, we can gain all the suitable feasible specialized chains. Then making a converse reasoning based on the generalized principle, we will finally integrate the schematic diagram of mechanism suitable for our design purpose. Therefore, if we make a kinematic and a dynamic analysis on mechanism based on this, after structural designing, we can find a new mechanical device whose performance is up to or even superior to that of the original product.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 1519-1522
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.1519
• Online since: January 2012
• Authors: Wan Chun Zhou, Jing Wang
• Keywords: Kinematic Chains, Link Assortment, Number Synthesis, Topological Structure

References

[1] Zhou. W. C, Zhou. T, and Wang. D, The innovative design of folding umbrellalike mechanism, Trans Tech Publications Ltd, Laubisrutistr. 24, Stafa-Zuerich, CH-8712, Switzerland, September, 2009, pp.109-112.

[2] Zhou, Wan-Chun and Zhang, Yong-Yu, Robot humanoid hand index finger type of creative design agency, 2010 The 2nd International Conference on Computer and Automation, IEEE Computer Society, 445 Hoes Lane - P.O. Box 1331, Piscataway, NJ 08855-1331, United States, February. 2010, pp.250-252.

DOI: 10.1109/iccae.2010.5451711

[3] Yan Hong-Sen, Yao Yan-An, Wang Yun-Xin and Guo Ke-Qian, Trans. Innovative Design of Machine. Beijing: Machinery Industry Press, 2002. 7.

[4] Cao Wei-Qing, The Analysis and Integration of Link Structure (2nd ed). Beijing: Science Press, 2002. Pg 1-58.
