Numerical Study of Liquid-Solid Impact Using Lagrangian-Eulerian Coupling Method

Abstract:

The fluid-structure interaction of a water droplet impact on a compressible solid has been studied. By using Lagrangian-Eulerian coupling method, the dynamics in water droplet and deformation in solid has been analyzed and discussed. It is shown that computational impact pressure on the central axis at the initial stage is in good agreement with theoretical prediction. The onset of jetting time is later than theoretical considerations and the incompressible stream line flow is not immediately established after the shock envelope overtakes contact periphery. The pressure at the contact periphery decreases gradually after shock wave departure. The deformation of solid is examined and found that the depression in the central impact area is considerably larger than the outer region. Comparisons with experimental observation show that the deformation simulated can account for the deformation patterns of metal in some way.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 1926-1932
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.1926
• Online since: January 2012
• Authors: Yong Qiang Han, Yong Hui Xie, Di Zhang
• Keywords: Deformation, Jet, Lagrangian-Eulerian Coupling Method, Liquid-Solid Impact

References

[1] J. Caldwell, Description of the Damage in Steam Turbine Blading due to Erosion by Water Droplets, Phil. Trans. Roy. Soc. London, vol. 260, p.204–208, Jul. (1966).

DOI: 10.1098/rsta.1966.0044

[2] Stanley S. Cook, Erosion by Water-Hammer, Proc. Roy. Soc. London, Ser. A, vol. 119, pp.481-488, Jul. (1928).

[3] M. B. Lesser, Analytic Solutions of Liquid-Drop Impact Problems, Proc. Roy. Soc. London, Ser. A, vol. 377, pp.289-308, Jul. (1981).

[4] F. P. Bowden, J. H. Brunton, The deformation of Solids by Liquid Impact at Supersonic Speeds, Proc. Roy. Soc. London, Ser. A, vol. 263, pp.433-450, Oct. (1961).

DOI: 10.1098/rspa.1961.0172

[5] J. H. Brunton, High Speed Liquid Impact, Phil. Trans. Roy. Soc. London, vol. 260, pp.79-85, Jul. (1966).

[6] J. E. Field, M. B. Lesser, J. P. Dear, Studies of Two-dimensional Liquid-Wedge Impact and Their Relevance to Liquid-Drop Impact Problems, Proc. Roy. Soc. London, Ser. A, vol. 401, pp.225-249, Oct. (1985).

DOI: 10.1098/rspa.1985.0096

[7] S. Sikalo, C. Tropea, E.N. Ganic, Impact of droplets onto inclined surfaces, Journal of Colloid and Interface Science, vol 286, 2005, pp.661-669, doi: 10. 1016/j. jcis. 2005. 01. 050.

DOI: 10.1016/j.jcis.2005.01.050

[8] Van Leer, B., Towards the Ultimate Conservative Difference Scheme. IV. A New Approach to Numerical Convection, Journal of Computational physics, vol 23, 1977, pp.276-299, doi: 10. 1016/0021-9991(77)90095-X.

DOI: 10.1016/0021-9991(77)90095-x

[9] Benson, D. J. , Momentum Advection on a Staggered Mesh, Journal of Computational Physics, vol 100, May 1992, pp.143-162, doi: 10. 1016/0021-9991(92)90316-Q.

DOI: 10.1016/0021-9991(92)90316-q

[10] M. B. Liu, G. R. Liu, K. Y. Lam, Investigations into water mitigation using a meshless particle method, Shock Waves, vol 12, 2002, pp.181-195, doi: 10. 1007/s00193-002-0163-0.

DOI: 10.1007/s00193-002-0163-0

[11] K. K. Haller, Y. Ventikos, and D. Poulikakos, Computational study of high-speed liquid droplet impact, Journal of Applied Physics, vol 92, Sep. 2002, pp.2821-2828, doi: 10. 1063/1. 1495533.

DOI: 10.1063/1.1495533

[12] G. P. Thomas, J. H. Brunton, Drog Impingement Erosion of Metals, Proc. Roy. Soc. London, Ser. A, vol 314, pp.549-565, Jan. (1970).
