Finite Difference Modeling of Elastic Wave Propagation

Abstract:

We present a staggered-grid finite difference scheme for velocity-stress equations to simulate the elastic wave propagating in transversely isotropic media. Instead of the widely used temporally second-order difference scheme, a temporally fourth-order scheme is obtained in this paper. We approximate the third-order spatial derivatives with 2N-order difference rather than second-order or other fixed order difference as before. Thus, it could be possible to make a balanced accuracy of O (Δt4+Δx2N) with arbitrary N. Related issues such as stability criterion, numerical dispersion, source loading and boundary condition are also discussed in this paper. The numerical modeling result indicates that the scheme is reliable.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 4656-4661
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.4656
• Online since: January 2012
• Authors: Qiang Zhang, Qi Zhen Du, Xu Fei Gong
• Keywords: Boundary Condition, Finite Difference, Numerical Dispersion, Staggered Grid, Velocity-Stress Equation

References

[1] Feng Ying-Jie, Yang Chang-Chun and Wu Ping, The review of the finite-difference elastic wave motion modeling, Progress in Geophysics, vol. 22, Apr. 2007, pp.487-491.

[2] Du Qizhen, Lin Bin and Hou Bo, Numerical modeling of seismic wavefields in transversely isotropic mediia with a compact staggered-grid finite difference scheme, Applied Geophysics, vol. 6, Mar. 2009, pp.42-49.

DOI: 10.1007/s11770-009-0008-z

[3] Alterman Z and Karal Jr F C, Propagation of elastic waves in layered media by finite difference methods, Bull. Seism. Soc. Am., vol. 58, 1968, pp.367-398.

[4] Madariaga R, Dynamics of an expanding circular fault, Bull Seism Soc. Am., vol. 65, 1976, pp.163-181.

[5] Dablain M A, The application of high-differencing to the scalar wave equation, Geophysics, vol. 51, 1986, pp.53-66.

DOI: 10.1190/1.1442040

[6] Levander A R, Four-order finite-difference P-SV seismograms, Geophysics, vol. 53, 1988, pp.1425-1436.

DOI: 10.1190/1.1442422

[7] Dong Liang-Guo, Ma Zai-Tian, Cao Jing-Zhong, Wang Hua-Zhong, Geng Jian-Hua, Lei Bing, Xu Shi-Yong et al., A staggered-grid high-order difference method of one-order elastic wave equation, China Journal of Geophysics, vol. 43, May 2000, pp.411-419.

DOI: 10.1002/cjg2.107

[8] Li M, Improvement to the staggered-grid high-order difference method of one-order elastic wave equation, Progress in Geophysics, vol. 24, June 2009, pp.1065-1068.

[9] Virieux J., P-SV Wave Propagation in Heterogeneous Media: Velocity-stress Finite Difference Method, Geophysics, vol. 51, 1986, pp.889-901.

DOI: 10.1190/1.1442147

[10] Virieux J., P-SV Wave Propagation in Heterogeneous Media: Velocity-stress Finite Difference Method,. Geophysics, vol. 51, 1986, pp.889-901.

DOI: 10.1190/1.1442147

[11] Dong Liang-Guo, Ma Zai-Tian and Cao Jing-Zhong, A study on stability of the staggered grid high-order difference method of first-order elastic wave equation, Chinese Journal of Geophysics, vol. 43, Nov. 2000, pp.856-864.

DOI: 10.1002/cjg2.107

[12] Wu Guo-Chen, Yang Hua-Zhong, Analysis of numerical dispersion in wave-field simulation, Progress in Geophysics, vol. 20, Mar. 2005, pp.58-65.

[13] Dong Qing-Hua, Numerical modeling for seismic origions, World Information on Earthquake Engineering, vol. 16, Sep. (2000).

[14] Cerjan C, Kosloff D, A none reflection boundary condition for discrete acoustic and elastic wave equation, Geophysics, vol. 50， 1985, pp.705-708.

DOI: 10.1190/1.1441945

[15] Saenger E. H. and Bohlen T., Finite-difference modeling of viscoelastic and anisotropic wave propagation using the rotated staggered grid, Geophysics, vol. 69, 2004, pp.583-591.

DOI: 10.1190/1.1707078
