Sliding Mode Variable Structural Control of Nonlinear Inverted Pendulum

Abstract:

In this paper, the multi-input linear and nonlinear mathematical differential equations of inverted pendulum system were established based on the traditional single-input linear inverted pendulum. Aiming at multi-input nonlinear model, nonlinear state transformation are carried through on the basis of the test of distribution involution and the calculation of integral manifold, then, the multi-input nonlinear inverted pendulum system was transformed into two single-input nonlinear inverted pendulum system to study. In the end, make use of related nonlinear system control theory of the sliding mode variable structure, designed the controller structure.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 74-80
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.74
• Online since: January 2012
• Authors: Jian Zhong Sun, Jian Kang Lu, Bin Yang, Jun Li Li
• Keywords: Inverted Pendulum, Multi-Input Nonlinear, Sliding Mode Variable Structure, State Transformation

References

[1] Utkin V. I, Sliding mode and their application in VSSs, Moscow, (1978).

[2] K. Furuta, Sliding mode control of variable structure control systems, System Control Lett. 1990, 14, 145~152.

DOI: 10.1016/0167-6911(90)90030-x

[3] Wang Fengrao, Sliding mode variable structure control, [M] Beijing, China Machine Press, (1998).

[4] Zhou Duan, Research on control of inverted pendulum, " [D] master, s thesis, Huazhong University of Science and Technology, (2007).

[5] Wang Xiaoli, Research on intelligent control system of inverted pendulum, " [D] master, s thesis, Shandong University, (2007).

[6] Huang Hongge, Linear inverted pendulum mechanism model and control performance research, " [D] master, s thesis, Central South University, 2008. Figure 1. Inverted pendulum and force analysis.
