A Portable Detecting and Analytic Instrument of Vibration Signal

Abstract:

It is often needed in engineering that detecting and analyzing vibration signal of some equipment. To meet the requirement, a portable detecting and analytic instrument was designed using virtual instrument concept. In the instrument, notebook computer was used as the platform of hardware. Vibration signal was obtained by integrated piezoelectric acceleration sensor (DTS0104T), and was transferred to a notebook computer through data acquisition card (NI USB-6210) based on USB bus. The software, running on the notebook computer, was developed under LabVIEW. Vibration signal could be displayed on screen, recorded in disk or printed by printer, retrieved, and analyzed. The analysis functions of the instrument include: time-domain analysis, frequency-domain analysis, time-frequency domain analysis, and correlation analysis. The instrument is compact, portable, powerful, and with friendly interfaces, has broad application prospects.

• Periodical: Advanced Materials Research (Volume 442)
• Pages: 305-308
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.442.305
• Online since: January 2012
• Authors: Jian Wei Li, Ling Wang, Hong Mei Zhang
• Keywords: Portable Instrument, Vibration Detection, Vibration Signal Analysis, Virtual Instrument (VI)
