Effect of Complex Agent on Copper Dissolution in Alkaline Slurry for Chemical Mechanical Planarization

Abstract:

With the microelectronic technology node moves down to 45 nm and beyond, and to reduce the RC delay time, low-k dielectric materials have been used to replace regular dielectric materials. Therefore, the down force of chemical mechanical planarization (CMP) needs to decrease based on the characteristics of low-k materials: low mechanical strength. In this study, the effect of new complex agent on copper dissolution in alkaline slurry for CMP was investigated. Based on the reaction mechanism analysis of Cu in alkaline slurry in CMP, the performance of Cu removal rate and surface roughness condition were discussed. It has been confirmed that Cu1 slurry demonstrates a relatively high removal rate with low down force. And also, by utilizing the Cu1 slurry, good result of Cu surface roughness were obtained.

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 1145-1148
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.1145
• Online since: January 2012
• Authors: Yan Gang He, Jia Xi Wang, Xiao Wei Gan, Wei Juan Li, Yu Ling Liu
• Keywords: Alkaline Slurry, Chemical Mechanical Planarization, Complex Agent, Copper

References

[1] T. Tucker: Chemical Mechanical Planarization of Semiconductor Materials, Spring-Verlag, Berlin, (2004).

[2] Y. Ein-Eli: D. Starosvetsky, Electrochim. Acta., vol. 52, pp.1825-1831, (2007).

[3] Y.J. Oh, G.S. Park, C.H. Chung, Journal of the Electrochemical Society, vol. 153, no. 7, p.617–621, (2006).

[4] I.I. Suni, B. Du, IEEE Transactions on Semiconductor Manufacturing, vol. 18, no. 3, p.341–349, (2005).

[5] A. Muthukumaran, V. Lowalekar, S. Raghavan, Materials Research Society Symposium Proceedings, vol. 914, p.231–236, (2006).

[6] D. Truque, Xiaolin Xie, Duane Boning, Materials Research Society Symposium Proceedings, pp.991-997, (2007).

[7] R.J. Gutmann et al., Thin Solid Films, vol. 270, no. 1, p.596–600, (1995).

[8] Q. Luo, S. Ramarajan, S.V. Babu. Thin Solid Films, vol. 335, no. 1, p.160–167, (1998).

[9] Q. Luo, S.V. Babu, Journal of the Electrochemical Society, vol. 147, no. 12, p.4639–4644, (2000).

[10] Y. Hong et al., Journal of Materials Research, vol. 20, no. 12, p.3413–3424, (2005).

[11] Yair Ein-Eli, David Starosvetsky: Electrochemical Acta, vol. 52, pp.1825-1838, (2007).

[12] M.R. Oliver: Chemical Mechanical Planarization of Semiconductor Materials, Springer, New York, (2004).

[13] E. Matijevic, S. V. Babu: J. Collid Inter. Sci., vol, 320, pp.219-296, (2008).

[14] J. Lu, J.E. Garland, C.M. Pettit: J. Electrochem. Soc., vol. 151, pp.717-721, (2004).

[15] V.R.K. Gorantla, K.A. Assiongbon, S.V. Babu: J. Electrochem. Soc., vol. 152, pp.404-409, (2005).
