Comparison of Different Residual Stress Models of FSW Butt Joints for Thin Aluminum Alloy Plates

Abstract:

At present, the main methods used to predict welding residual stresses are the three dimensional thermo-elastic-plastic FEA method and the inherent method.Many learners had simulated the residual stresses of FSW used the thermo -elastic-plastic FEA method which was proved to be time consuming and not very effective. The inherent strain method neglects the whole welding process, and predicts distortion using an elastic finite element analysis by applying the inherent strains on the structure. In this paper,the inherent strains are firstly obtained for an flat butt-joint of aluminum alloy through experiments and three dimensional thermo-elastic-plastic FEA. Computational and experimental results showed that the inherent strain method could predict welding distortion with acceptable accuracy and greatly reduced running time when comparing to the thermo-elastic-plastic FEA method.

• Periodical: Advanced Materials Research (Volumes 463-464)
• Pages: 642-646
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.463-464.642
• Online since: February 2012
• Authors: Xi Jing Wang, Na Li, Zhong Ke Zhang, Guo Jing Ruan
• Keywords: Friction Stir Welding (FSW), Inherent Strain Method, Residual Stress, Thermo-Elastic-Plastic FEA

References

[1] Mishra R S, Ma Z Y. Friction stir welding and processing[J] . Materials Science and Engineering R, 2005, 50: 1-78.

[2] Mir Zahedul.H. Khandkar, Jamil A. Kan, Anthony P. Reynolds, Michael A. Sunon. Prediction residual thermal stresses in friction stir welded metals [J]. Journal of Materials Processing Technolgy. 2006(174): 195~203.

DOI: 10.1016/j.jmatprotec.2005.12.013

[3] Ueda Y, Kim Y C, Yuan M G. A prediction method of welding residual stress using source of residual stress (Report I) - Characteristics of inherent strain ( source of residual stress ) [ J] . J Trans. Of JWRI, 1989, 18( 1) : 135~141.

DOI: 10.1080/09507119209548183

[4] Wang Jianhua, Lu Hao, Murakaw a Hidekazu. Mechanical behavior in local post weld heat treatment ( Report I) viscoelastic plastic FEM analysis of local PWHT [J] . Trans JWRI, 1998, 27( 1) : 83- 88.

[5] Jang CD, Seo SI, Ko DE (1997) A study on the prediction of deformations of plates due to line heating using a simplified thermal elasto-plastic analysis. J Ship Prod 13: 1.

DOI: 10.5957/jsp.1997.13.1.22

[6] Wang Jianhua, Lu Hao. Prediction of welding deformations by FEM based on inherent strains[J]. Journal of Shanghai Jiao tong University(in ENGLISH), 2000, 5(2): 83~87.

[7] Luo Y. Mulakawa H , Ueda Y. Prediction of welding deformation and residual stress by elastic FEM based on inherent strain (Report I)[J] . Trans. JWRI, 1997, 26(2): 49~57.

[8] M young S H. Fundamental studies on welding induced distortion in thin plates [D] Ph. D. Thesis , Ohio State University , Columbus , O2 hio , USA , (2002).

[9] Li Hong. Prediction of welding deformations of stiffened plate based on inherent strain[D]. Harbin: Harbin Engineering University, (2005).
