A Novel Force Sensor Based Multi-Function Take-Off Board

Abstract:

In order to detect the take-off forces of athletes in long jump, a novel force sensor based take-off board is designed. The take-off board consists of a standard take-off board, two novel force sensors, two support plates and a base. The working mechanism of the strain beam in the force sensor is analyzed and the finite element method(FEM) is used to investigate the structural deformation and stress distribution. Then the sensor is tested. The calibration experimental results demonstrate that the sensor has an excellent measurement linearity (0.6%) and can meet the requirements of practical applications. Then the multi-function take-off board based on the force sensors is designed and manufactured which can make the daily long jump training more scientific.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 221-224
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.221
• Online since: February 2012
• Authors: Pei Chen, Yu Long Zhao, Bao Jin Wang, Shan Ping Chen, Zhen Long Yan
• Keywords: Force Sensor, Long Jump, Multi-Function Take-Off Board, Strain Gauge

References

[1] A.Seyfarth, A.Friedrichs, V.Wank, R.Blickhan: Journal of Biomechanics. Vol.32 (1999), p.1259

DOI: 10.1016/s0021-9290(99)00137-2

[2] Nicholas P. Linthorne, Craig Baker, Montell M.M. Douglas, Gary A. Hill and Richard G. Webster: Portuguese Journal of Sport Sciences. Vol.11 (2011)

[3] LI Kejie: Handbook of Sensor Technology (National Defense Industry Press, China 2002)

[4] FANG Li, SUN Yining, WANG Lili: Journal of Transducer and Technology. Vol.27(7)(2002), p.49 (In Chinese)
