An Adjustable Voltage Signal Filament Conversion Alarm System

Abstract:

A new adjustable voltage signal filament conversion alarm system is proposed which based on the traditional conversion monitoring system of train signal filament. This system adopts the embedded DSP processor monitoring the state of filament and uses the DSP to control PWM (Pulse-Width Modulation) duty cycle for preheating the filament，then gradually lit it. It avoids the breakdown of the filament break. The power line carrier technology is used for alarming signal transmission. This system is more practical than the traditional, which shortens filament switch time and improves the alarm accuracy.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 699-703
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.699
• Online since: February 2012
• Authors: Bao Feng Zhang, Jin Feng Yang, Jun Chao Zhu
• Keywords: Digital Signal Processor (DSP), Filament Transfer, PWM, Signal

References

[1] Weizhong Wu: By using the computer control technology to improve the signal in the station filament alarm system, Railway construction technology. (2006).

[2] Yumei Li: Filament check discussed of shunting signal filament lamp, Railway communication signal engineering technology. (2010).

[3] Chengtao Cao, Genglin Guo, Jianmin Xu: Intelligent traffic signal controller design and implementation, Computer engineering and applications. (2010).

[4] Boqing Huang, Huixian Huang: Ethernet-based intelligent traffic signal system, Computer measurement and control. (2011).

[5] Juan Liang, Shiru Qu: Based on the MC-51 and CPLD intelligent signal controller driving design, Industrial instrumentation and automation equipment. (2008).
