Analysis of Directional Accuracy of Three Single Arrays

Abstract:

Acoustic sensoxr array technology is the one of the key technology of passive acoustic detection technology, whether the single array has a good performance on direction will directly affect the accuracy of the locating system. In order to choose the best single array on direction, in this paper, respectively selected representative plane array and spatial array from a number of typical single arrays to analyze, find out the advantages and disadvantages of two single arrays. On this basis, around the idea of integrating the advantage of symmetric spatial array and plane cross five-element array, according to characteristics of the structure of this two kinds of arrays to design a new locating model—spatial five-element array. And compared with two kinds of single array mentioned above, the results of comparison show that the locating accuracy of spatial five-elements array is superior to both kinds of mentioned, and have high engineering value.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 1714-1717
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.1714
• Online since: March 2012
• Authors: Li Qing Fang, Hong Kai Wang, Kai Chen
• Keywords: Locating, Passive Acoustic Detection Technology, Single Array, Symmetric Spatial Five-Element Array

References

[1] Yunde Jia, Shulin Leng, et al. Modeling of passive acoustic sensing with four-sensor array for target location, ACTA armamentar, Mag. China, vol. 22, pp.206-209, May (2001).

[2] Tawfik, A. A generic processing structure decomposing the beamforming process of 2-D and 3-D arrays of sensors into sub-sets of coherent process[C]. Radio Science Conference, 1999. NRSC'99. Proceedings of the Sixteenth National, 2001, 3: 1658-1661.

DOI: 10.1109/nrsc.1999.760909

[3] Lo, K.W.; Ferguson, B.G. Flight path estimation using frequency measurements from a wide aperture acoustic array[C]. Aerospace and Electronic Systems, IEEE Transactions on, 2001, 37(2): 685-694.

DOI: 10.1109/7.937479

[4] Edelson, G.S.; Tufts, D.W. On the performance of conventional and unconventional towed arrays[C]. OCEANS, 2001. MTS/IEEE Conference and Exhibition, 2001, 3: 1707-1714.

DOI: 10.1109/oceans.2001.968090

[5] Wang Hongkai, Fang Liqing, Xiong Chao. Location Algorithm and Precision Analyzing of spatial five-element cross array[J]. ordnance industry automation, 2011(8).
