A Linear Algorithm of Spatial Straightness for Five Points

Abstract:

It is a non-linear problem to evaluate the minimum zone spatial (3-D) straightness. Because of the disadvantages of evaluating spatial straightness error with traditional method, such as difficulty in solving the non-linear equation, the evaluating precision is lower. This paper develops a solution that can transform the non-linear problem into a linear problem. The solution can obtain more exact results than traditional method using results of LSC as initial conditions. This methodology can also be applied to the problems of computing the minimum circumscribed cylinder and the maximum inscribed cylinder. The effectiveness and efficiency of the novel approach are illustrated by two examples.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 1888-1892
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.1888
• Online since: March 2012
• Authors: Fan Wu Meng, Chun Guang Xu, Juan Hao
• Keywords: Linear Algorithm, Minimum Circumscribed Cylinder, Spatial Straightness

References

[1] Huang S.T., Fan K.C. and Wu J.H. : Prec Eng 1993; 15(3): 158–65.

[2] Carr K and Ferreira P: Prec Eng 1995; 17(2): 144 –55.

[3] Fugui Huang and Changcai Cui: Chinese Journal of Mechanical Engineering, 2008 (44) : 221-224. (in Chinese).

[4] Xiulan Wen and Aiguo Song: International Journal of Machine Tools & Manufacture，2003(43): 1157–1162.

[5] Q. Zhang, K.C. Fan and Z. Li: Prec Eng 23 (4) (1999) 264–272.

[6] Jyunping Huang: Prec Eng 23 (3) (1999) 204–208.

[7] Wenwen Liu and Yetai Fei: JOURNAL OF CHINA UNIVERSITY OF SCIENCE AND TECHNOLOGY, 29 (2) 242-247. (in Chinese).

[8] Q. Zhang, and Z. Li: Measurement Technique 1998 (1): 9–12. (in Chinese).
