Parametric Design of Spiral Bevel Gear Based on Pro/E

Abstract:

Considering the influence of the cutter head plane on manufacturing of spiral bevel gear, the method of 3D model for spiral bevel gear is built based on Program Pro/E. The relationship between the geometric parameters (such as addendum circle, dedendum circle and base circle) and the basic parameters (such as modulus and the number of teeth) of spiral bevel gear is established by using the inner program. The parametric solid model of spiral bevel gear can be obtained automatically by rotation, sweep, blend, and pattern after inputting the basic parameters. This method is significant to improve the accuracy of design and manufacturing of spiral bevel gear.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 2454-2458
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.2454
• Online since: March 2012
• Authors: Wei Wang, Wei Liu, Yan Chi, Xiao Mei Cui
• Keywords: Cutter Head Plane, Parametric Modeling, Pro/E, Spiral Bevel Gear

References

[1] Lin Aiqin, Kai Huang: Journal of Liaoning Institute of Technology Vol. 24(2004) , pp.30-32, In Chinese.

[2] Zhaobo Ran, Chaoyan Wan: Machinery Vol. 34(2007) , pp.35-37, In Chinese.

[3] S. -H. Suh, D. -H. Jung, E. -S. Lee et. al: The International Journal of Advanced Manufacturing Technology. London, Vol. 21(2003), pp.775-786.

[4] Lianying He: Journal of Xinjiang University Vol. 19(2002), pp.379-380, In Chinese.

[5] Shanming Luo, Jian Wang, Xiaoling Wu et. al: Journal of Mechanical Transmission Vol. 30(2006), pp.26-28, In Chinese.

[6] Xiushan Wang, Shumin Zhang: Journal of China Agricultural University Vol. 9(2004). pp.84-86, In Chinese.
