Cutting Tool Selection through Tool Wear, Cost, Power Consumption and Surface Roughness Analyses

Abstract:

The current requirements for an efficient dimensional inspection of manufactured parts have lead to development of different in process and on-machine measurement (OMM) techniques. Touch trigger probes (TTP) are the most common technologies utilized, inspired on contact probes used on coordinate measuring machines (CMMs). The on-machine accuracy of TTPs depends upon precision of the tool-machine control as well as upon the procedure for TTP presetting. Taking this into account, a different OMM technique is considered in this work, which consists on a laser micrometer (LM) that is commonly used for in-process measurement of continuous products. The behaviour of TTP and LM is analysed and discussed in terms of repeatability and reproducibility. Results obtained by both techniques are compared each other by measuring a cylindrical workpiece and by checking the results with those obtained on a CMM.

• Periodical: Advanced Materials Research (Volume 498)
• Pages: 55-60
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.498.55
• Online since: April 2012
• Authors: Guillem Quintana, Maria Luisa Garcia-Romeu, Joaquim Ciurana
• Keywords: Computerized Numerical Control (CNC), Cutting Tool, Manufacturing, Productivity, Tool Wear

References

[1] Y. Altintas: Manufacturing automation, metal cutting mechanincs, machine tool vibrations, and CNC design (Cambridge University Press, USA 2000).

DOI: 10.1017/cbo9780511843723

[2] M. Arnone: Mecanizado de alta velocidad y gran precisión (El MT, Spain 2000).

[3] L.N. López de Lacalle, J.A. Sánchez and A. Lamikiz: Mecanizado de alto rendimiento. Procesos de arranque (Ediciones Técnicas Izaro, Spain 2004).

[4] J. Ciurana, G. Quintana and M.L. Garcia-Romeu: Int. J. of Prod. Econ. Vol. 115(1), pp.171-178.

[5] G. Quintana, J. Ciurana and F.J. Campa: (2008). Chapter 3 Machine tool spindles. In López de Lacalle, L.N. and Lamikiz, A. (Eds. ), Machine tools for high performance machining (pp.75-127).

DOI: 10.1007/978-1-84800-380-4_3

[6] E. Oberg and C.J. McCauley: (2004) Machinery's handbook: a reference book for the mechanical engineer, designer, manufacturing engineer, draftsman, toolmaker, and machinist; New York; Industrial Press.

[7] L.N. López de Lacalle and R. Urizar: Fresado de alta velocidad: proceso, materiales y aplicaciones (Ediciones Técnicas Izaro, Spain 1999).

[8] M. Alauddin , M.A. El Baradie and M.S.J. Hashmi: J. of Mat. Process. Tech. Vol. 71(3) (1997), pp.456-465.

[9] A. J. Vallejo, R. Morales-Menendez and J.R. Alique: Intelligent Monitoring and Decision Control System for Peripheral Milling Process; 2008 IEEE International Conference on Systems, Man and Cybernetics (SMC 2008).

DOI: 10.1109/icsmc.2008.4811519

[10] T. Ozel and Y. Karpat: Int. J. of Mach. Tools and Manuf. Vol. 45(4-5) (2005), pp.467-479.

[11] ISO-4288. Geometrical Product Specifications (GPS), Surface texture: Profile method, Rules and procedures for the assessment of surface texture. ISO-4288 (1996).

DOI: 10.3403/02337030

[12] ISO-4287. Geometrical Product Specifications (GPS), Surface texture: Profile method, Terms, definitions and surface texture parameters. ISO-4287 (1997).

DOI: 10.3403/30398213
