The Finite Element Simulation of Milling Based on Orthogonal Cutting Model

Abstract:

The paper make the service life of relieving formed milling cutter as the optimization objective, proceed the simulation study on the mechanical degree of cutter, cutting data. The concrete method is that the orthogonal milling model is established to simulate the simulation milling process, some basic parameters which are obtained in the machining process are analyzed and discussed. The results indicate that the finite element simulation of the metal cutting processing can analyze quantitatively some physical properties, such as the cutting force, stress, strain and so on, the traditional way of qualitative analysis is changed. The state of machining is in favour of grasping in the theory, the theory and technology are provided to establish the proper processing technology strategy.

• Periodical: Advanced Materials Research (Volume 499)
• Pages: 208-212
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.499.208
• Online since: April 2012
• Authors: Ai Hua Gao, Fu Rong Wang, Jian Xin Zhang
• Keywords: Cutting Data, Cutting Model, Finite Element (FE) Simulation, Milling Process

References

[1] Zhu Jiangxin, Yang Ping. Tool Engineering, Vol. 44(2010), p.25. (In Chinese).

[2] Yue Duiqian. Metal Cutting Tools. Beijing, China Machine Press, (1992), p.64. (In Chinese).

[3] Xie L J, J Schmidta, C Schmidta, et a1. Wear, Vol. 258(2005), p.1480.

[4] Huang Zhi Gang, Ke Ying Lin, Dong Hui Yue. Journal of Zhejiang University(Engineering Science), Vol. 39(2005), p.368. (In Chinese).

[5] Jin Quangdong, Shi Yunxu, BAE Yeongho. Hot Working Technology. Vol. 39(2010), p.20. (In Chinese).

[6] Wu Xuesong, Liu Peide. Chinese Journal of Stress Mechanics. Vol. 2(1985), p.3. (In Chinese).
