Experimental Study on Ball Sealer Diversion for Lateral Well

Abstract:

Simulation lateral well for ball sealer diversion was established in this paper. Experiments under different conditions were conducted in the laboratory. The results show that ball sealer diversion technique can really improve water injection profile. When the number of blocking balls in one layer is less than 10, flow rate change of layers is not obvious. When the number of blocking balls is more than 10, flow rate of the layer reduces quickly. When the formation variation coefficient is 0.62 and 0.79, the goal of ball sealer is very clear. Generally 42 to 48 balls are needed to achieve good diversion effect. Balls injected near the target layer can improve diversion effect, and increase of total flow rate can improve diversion effect. In the experiment, the overall utilization rate of the injected balls is from 30% to 50%, and accurate blocking rate is from 20% to 30%.

• Periodical: Advanced Materials Research (Volumes 524-527)
• Pages: 1399-1407
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.524-527.1399
• Online since: May 2012
• Authors: Song Yan Li, Zhao Min Li
• Keywords: Ball Sealer Diversion, Experiment, Lateral Well, Water Injection Profile

References

[1] Xiao Zhao and Ruiqing Li. 2005. Ball sealer diversion technology used in heavy oil. Oil-gasfield surface engineering, 24(12): 52-53.

[2] Tongwen Sun and Yongan Liu. 2003. Studies on technology of water injectivity profile modification by using rigid plastic balls as perforation closer. Oilfield Chemistry, 20(1): 20-22.

[3] Yongan Liu and Tongwen Sun. 2001. Design and manufacture of rigid plastic balls as perforation closer for modifying injectivity profile in water injection wells. Oilfield Chemistry, 18(2): 129-132.

[4] Tongwen Sun, Yongan Liu, Zongkui Niu, et al. 2003. Water injection profile modification by temporary unidirectional perforation close with rigid plastic balls and successive acidizing. Oilfield Chemistry, 20 (2): 119-120.

[5] Huixiong Li, Hefei Luan, and Tingkuan Chen. 2002. Simulation test on the technology for controlling injected-water profiles with floating spheres. Oil Drilling & Production Technology, 24(5): 40-42.

[6] Xihua Long and Tongwen Sun. 2002. Computer simulation for ball sealer diversion. Oil-gasfield surface engineering, 21(1): 81-82.

[7] Brown R. W. and Loper R. G. 1959. Stimulation treatment selectivity through perforation ball sealer technology. Petroleum Engineering.

[8] Derrick J.V. and Kaltenberger, L.H. 1956. Method of temporarily closing perforations in the casing. U.S. Patent No. 2,754,910

[9] George H. Neill, Robert Wade Brown, and Charles M. Simmons. 1957. An inexpensive method of multiple fracturing. Drilling and Production Practice, 27-32

[10] Harrison N.W. 1972. Diverting agents – their history and application. Journal of Petroleum Technology, 24(5): 593-598.

DOI: 10.2118/3653-pa

[11] Brown R. W., Neill G.H., and Loper R.G. 1963. Factors influencing optimum ball sealer performance. Journal of Petroleum Technology, 15(4): 450-454.

DOI: 10.2118/553-pa

[12] Erbstosser S.R. 1978. Well treatment fluid diversion with low density sealers. U.S. Patent No. 4,102,401

[13] Erbstoesser S.R and Shaughnessy C.M. 1980. Method for placing ball sealers onto casing perforation. U.S. Patent No. 4,195,690

[14] Erbstoesser S.R. 1980. Improved ball sealer diversion. Journal of Petroleum Technology, 32(11): 1903-1910.

DOI: 10.2118/8401-pa

[15] Bale G.E. 1984. Matrix acidizing in Saudi Arabia by using buoyant ball sealers. SPE 11500, 1748-1752.

DOI: 10.2118/11500-pa

[16] Dean M.Bilden and Lewis L.Lacy. 1996. New water-soluble perforation ball sealers provide enhanced Diversion in Well Completions. SPE 49099: 427-436.

DOI: 10.2118/49099-ms

[17] Pascal Baylocq, Jean Jacques Fery, and Laurent Parra. 1999. Ball sealer diversion when fracturing long and multiple Triassic sand intervals on Alwyn field, North Sea. SPE 54740: 1-10.

DOI: 10.2118/54740-ms

[18] Li X., Chen Z., and Chaudhary S. 2005. An Integrated Transport Model for Ball-Sealer Diversion in Vertical and Horizontal Wells. SPE 96339: 1-9.

DOI: 10.2118/96339-ms
