Research on Nozzle Array Structure Fluidic Gyroscope Sensitivity-Temperature Compensation

Abstract:

The nozzle array structure fluidic gyroscope sensitivity-temperature compensation was researched. The fluidic gyroscope’s sensitivity temperature characteristic was analyzed in the sensitive element and two sensitivity-temperature compensation methods were compared. Then, the software compensation method was used, which based on the Single chip microcomputer technology and realized sensitivity compensation for the gyroscope output signal. The results show that after the compensation, the gyroscope’s sensitivity-temperature coefficient decreases from 1.8mV/°/s/°C to 0.1mV/°/s/°C and operating temperature range increases from normal temperature to -40°C～+60°C. Therefore, this method provides the effective way for the gyroscope practical research.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 806-809
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.806
• Online since: June 2012
• Authors: Xing Wang, Lin Hua Piao, Quan Gang Yu
• Keywords: Fluidic Gyroscope, Nozzle Array Structure, Sensitive Principle, Sensitivity-Temperature Compensation

References

[1] Van Thanh Dau, Otake Tomonori, Thien Xuan Dinh, etal. Proceeding of IEEE Sensors Conference, pp.666-669, (2008).

[2] V.T. Dau, T.Otake, T.X. Dinh. Proceeding of Actuators and Microsystems Conference, pp.1170-1173, (2009).

[3] Thien Xuan Dinh, Van Thanh Dau, Susumu Sugiyama, et al. Journal of Sensors and Actuators B: Chemical, vol.150, pp.819-824,( 2010).

[4] Linhua Piao, Jinduo Zhang, Fuxue Zhang. Journal of Piezoelectrics & Acoustooptics, vol.27, pp.309-311, (2005). (In Chinese)

[5] Guidong Luan, Jinduo Zhang, Huanyang Jin. "Sensor and Its Application. Xi'an Electronic Science and Technology University Press, (2002).(In Chinese)
