Three-Dimensional Virtual Design and Simulation Analysis of Dual-Side-Load Trailer

Abstract:

Based on virtual modeling technology and multi-body dynamics theory, three-dimensional virtual design and dynamics simulation was completed in this paper. Basic flow and general method of layout design of product using of 3D computer aided design software was presented. The frame model of layout was completed based on the structure and performance requirements of the dual-side-load trailer and 3D software’s CAD technology including parametric and variational technology and top-down design method. Based on the frame model, the layout design of the trailer was completed and the three-dimensional digital model was established. Took the lifting mechanism of the trailer as an example, based on its structure and operation principle, kinematics and dynamics simulation to each of the typical operation processes was completed.

• Periodical: Advanced Materials Research (Volume 548)
• Pages: 657-661
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.548.657
• Online since: July 2012
• Authors: Xiang De Meng, Li Shun Li, Hong Xun Li, Jun Qing Zhan
• Keywords: Dual-Side-Load Trailer, Dynamic, Kinematics, Simulation, Virtual Design

References

[1] Zhan junqing, Structure and design of military special purpose vehicle, Beijing: National Defence Industry Press. 2003. 05. (in Chinese).

[2] You chunfeng, Advanced application of CATIA V5, Beijing: Tsinghua University Press. 2006. 01. (in Chinese).

[3] Li lishun，Meng xiangde. Virtual design and kinematic simulation of palletized loading system based on SolidWorks. Hoisting and Conveying Machinery, 2007(3). (in Chinese).

[4] Meng xiangde, Zhan junqing. Dynamics simulation study of dual-side-load trailer's lifting mechanism. Hoisting and Conveying Machinery, 2008(8). (in Chinese).

[5] Meng xiangde，Zhang Junhong. Design of Compact Multiple Support Mechanism for Special Purpose Vehicles. ICMTMA2011, Vol. 1, pp.946-949.

DOI: 10.1109/icmtma.2011.237

[6] Meng xiangde，Zhan Junqing. Design and simulation analysis for virtual prototype of self-loading and unloading system. Modern Manufacturing Engineering, 2007(1). (in Chinese).
