Mechanical Behavior of Overlap-Welded of Dissimilar Steels (Structural-Stainless) under Monotonic Load

Abstract:

The research shows the characterization of mechanical properties in dissimilar steel welded unions: a structural steel ASTM A537 (I) overlap welded with an austenitic stainless steel ASTM A240 (304L) through semiautomatic electrical arc welding process protected by inert gas (GMAW); Argon is used as a protecting gas and austenitic stainless steel ASTM A240 (308L) as a supplier material. Samples were tested in not welded conditions so as to characterize the materials involved in the research, and they were also tested in welded conditions, not being submitted to pre and post welding Thermal Treatment (TT). Welded-based material samples were characterized through Optical Microscopy (OM) and Scanning Electron Microscopy (SEM), an inspection of Not Destructive Test (NDT) with penetrating liquids and ultrasound was also conducted. The following mechanical tests were completed, not only on the Base Metals (BM), on the Welding Join (WJ) as well: Vickers micro hardness profile, tension, and face bending test. Results showed a proper mechanical steel behavior, welded by GMAW procedure, under monotonic, in spite of the relatively high values of microhardness in the Heat Affected Zone (HAZ), specifically near the fusion line between weld and stainless steel.

• Periodical: Advanced Materials Research (Volumes 557-559)
• Pages: 1268-1274
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.557-559.1268
• Online since: July 2012
• Authors: Andrés L. García Fuentes, Pierre Bazán, Leiry Centeno, Magaly Ramos, Alberto Velázquez Del Rosario
• Keywords: Dissimilar Welding, GMAW, Heat Affected Zone (HAZ), Stainless Steel (SS), Structural Steel

References

[1] García, A, Centeno, L, Salas, R, y Velázquez, A, Metallurgy of dissimilar steels welded unions (ASTM A240–A537) and mechanical behavior under monotonic and cyclic loads. Latin American Journal of Metallurgy and Materials, pISSN: 0255-6952 | eISSN: 2244-7113. 24 May 2011.

[2] ASTM A240/A240M(2001). Standard Specification for Heat-Resisting Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip for Pressure Vessels.

DOI: 10.1520/a0167

[3] ASTM A537/A537M-95 (2000). Standard Specification for Pressure Vessel Plates, Heat-Treated, Carbon-Manganese-Silicon Steel.

DOI: 10.1520/a0537_a0537m

[4] ANSI/AWS A5.9/A5.9M-2006: Corrosion - Resisting Chromium and Chromium - Nickel Steel Bare and Composite Metal Cored and Stranded Welding Electrodes and Welding Rods. Miami (EE.UU.): American Welding Society, 2006.

DOI: 10.1520/a0371

[5] Dieter GE, Mechanical Metallurgy. New York. McGraw-Hill. Third Edition. 1986. Chapter 6.

[6] ASME CODE. Section IX. Welding and Brazing Qualifications (American Society of Mechanical Engineers). 2007.

[7] Welding handbook, Vol. 1. AWS Handbook (American Welding Society), Eighth Edition. 2007.

[8] ASME CODE. Section VIII, Pressure Vessel Design. Divisions I & II. (American Society of Mechanical Engineers). 2007.

[9] ASTM E3-01 Standard Practice for Preparation of Metallographic Specimens. Philadelphia (EE.UU.): American Society for Testing and Materials, 2001.

[10] ASTM E92-82(1997)e3 Standard Test Method for Vickers Hardness of Metallic Materials. Philadelphia (EE.UU.): American Society for Testing and Materials, 1997.

[11] ASTM E8M-01e1 Standard Test Methods for Tension Testing of Metallic Materials [M]. Philadelphia (EE.UU.): American Society for Testing and Materials, 2001.

[12] ASTM E190-92 (1997) Standard Test Method for Guided Bend Test for Ductility of Welds. Philadelphia (EE.UU.): American Society for Testing and Materials, 1997.

[13] Sindo, K, Welding Metallurgy. Department of Materials Science and Engineering University of Wisconsin (EE.UU.): John Wiley & Sons, INC, Publication, 2002, Second Edition.

[14] ASTM E112-96e1 Standard Test Methods for Determining Average Grain Size. Philadelphia (EE.UU.): American Society for Testing and Materials, 1996.

[15] GARCÍA, A. "Physical metallurgy of dissimilar steels (ASTM A240-A537) welded unions and mechanical behavior under monotonic and cyclic loads".10th International Fatigue Congress, Institute of Physics of Materials of the Academy of Sciences, Czech Republic. Prague. 2010.
