Influence of Slide Stroke Curves on Forming Quality of Box Shaped Part during Deep Drawing

Abstract:

To explore the influence of slide stroke curves on deep drawing and solve the problems of cracking and wrinkling during drawing, the deep drawing processes of box shaped part with the conventional mechanical press and servo press were simulated, respectively. The variation rules of cracking and wrinkling for box shaped part by different slide stroke curves were obtained. It shows that the qualified parts can be obtained more easily when drawing with servo presses by decreasing the rotational speed of servo motor at the forming stage due to its variability; drawing cycle can be shorten effectively by adjusting the variable displacement-velocity curves of servo press.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 1177-1181
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.1177
• Online since: August 2012
• Authors: Qin Xiang Xia, Teng Xu, Zhen Shi Li, Wei Ping Ruan
• Keywords: Box Shaped Part, Conventional Mechanical Press, Deep Drawing, Servo Press, Variable Displacement-Velocity Curve

References

[1] X.F. Lu: Stamping Forming Technology and Mould Design. 2nd ed. Beijing: China Machine Press, (2005), pp.67-68.

[2] Z.Y. Huang, F. Ruan, X. Zhang: Development and Application of the Servo Stamping Technology. Proc 6th forging and pressing annual meeting of Pan pearl river delta. Fuzhou China, (2011) pp.8-12.

[3] J.C. Min, C.H. Yan, C.Z. Qi: Characters and Applications of Servo Press. Metal working, vol23, (2010), pp.6-10.

[4] Y.S. Sun, X.H. Zhou, M. Li: AC servo presses and their key technique. Forging & Stamping Technology, vol 33(04), (2008), pp.1-8.

[5] Y. Lu, J.G. Zhou, S. Ruan: The Newest Development of Servo Press and Future. China Metal Forming Equipment & Manufacturing Technology, Vol. 07, (2006), pp.11-14.

[6] X.P. Wang: Stamping process manual. 2nd ed. Beijing: China Machine Press, 2005, pp.226-240.

[7] H.Q. Yu, J.D. Chen: Fundamental of Metal Plastic Forming. Beijing: China Machine Press, (2007), pp.157-158.

[8] R.G. Ma: Comparative research of drawbeads based on Automobile lampshade parts. Kunming. Kunming University of Technology. (2007).

[9] Y.Q. Wang: Automatic Control Theory. Beijing, Tsinghua University Press, (2008).

[10] M.P. Dun, Y. Cheng, and Y. Li: Influence of drawing velocity on workpiece split. Forging& Stamping Technology. Vol 04, (2001), pp.28-29.

[11] J. Li: Servo Press Development and Application. CFHI Technology. Vol 05, (2010), pp.1-5.
