The Optimal Cutter Length Determining for Fixed 5-Axis Milling

Abstract:

Fixed 5-axis milling machining has been the most preferred method in fabricating dies and molds with very deep shapes. In the process planning of such machining, determining of the cutter length is a time consuming task. In this paper, an algorithm for automatically determining the optimal cutter length for the fixed 5-axis milling operation is proposed. The optimal length can be derived by computing the distance between the cutter location points and an offset shape of the workpiece by the inverted zero-length cutter. These computations of the offset shape can be accelerated by using the depth buffer mechanism of GPU which is now installed on most PCs. An experimental system is implemented and some computational experiments are performed.

You might also be interested in these eBooks

Machine Design and Manufacturing Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 566)

Pages:

203-206

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.566.203

Citation:

Cite this paper

Online since:

September 2012

Authors:

Wen Li Huang, Masatomo Inui, Zhi Hui Shi

Keywords:

Cutter Length, Fixed 5-Axis Milling Machine, Inverted Offset Method

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] S.J. Kim, in Short and Safe Tool Setting by Safe Space in NC Machining, International Journal of Advanced Manufacture Technology, Vol. 33 (2007), pp.1017-1023.

DOI: 10.1007/s00170-006-0526-2

Google Scholar

[2] Morimoto K, Inui M, A GPU based Algorithm for Determining the Optimal Cutting Direction in Deep Mold Machining. Proc. IEEE International Symposium on Assembly and Manufacturing 2007: 203-208.

DOI: 10.1109/isam.2007.4288473

Google Scholar

[3] W. Huang and M. Inui, in An Algorithm for Determining the Optimal Cutter Length in 3-Axis Milling, Proc. 2009 IEEE International Conference on Mechatronics and Automation (2009 ICMA), pp.1979-1984, (2009).

DOI: 10.1109/icma.2009.5246730

Google Scholar

[4] Choi B.K., Jerard RB, in Sculptured Surface Machining. Kluwer Academic Publishers, Dordrecht. (1998).

Google Scholar

[5] M. Inui and T. Miyashita: Hollow Shape Extraction: Geometric Method for Assisting Process Planning of Mold Machining, Proc. 2003 IEEE International Symposium on Assembly and Task Planning (ISATP 2003) pp.30-35.

DOI: 10.1109/isatp.2003.1217183

Google Scholar

[6] Inui M, Ohta A., in Using GPU to Accelerate Die and Mold Fabrication. IEEE CG&A Magazine, 2007; 27(1): 82-87.

DOI: 10.1109/mcg.2007.23

Google Scholar
