Maximum Output Operation by Equivalently Field Weakening and Optimal Parameters of BLDC Motor

Abstract:

Permanent-magnet brushless direct-current motors are easy to maintain, compared with direct-current motors. Therefore, they are attracting attention. In this paper, the authors discuss a non-salient pole brushless direct-current motors. Usually, the quadrature armature current which contributes to torque generation is supplied in this motor. But, in this case that the source voltage cannot be increased by supplying the direct armature current, that is, equivalently field weakening, a quadrature armature current can be increased. Consequently, the motor torque increases. In the case that the load characteristics are settled, the motor torque can have a maximum Tm by adjusting a direct armature current. At this time the rotational speed and output are maximum also. Tm changes with the change of the motor parameters. Consequently, the motor parameters which maximize Tm are optimal. In this paper, the authors have clarified an optimal parameter determination method considering by the load torque-speed characteristics and, armature resistance by the power factor, and efficiency where the motor has optimal parameters and generates the maximum output. Furthermore, the theory obtained has been confirmed experimentally by the authors.

You might also be interested in these eBooks

Machine Design and Manufacturing Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 566)

Pages:

170-181

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.566.170

Citation:

Cite this paper

Online since:

September 2012

Authors:

Komatsu Yasuhiro, Syed Abdul Kadir Zawawi, Yoshihiko Araki

Keywords:

Brushless Dc Motor (BLDCM), Equivalently Field Weakening, Load Characteristic, Maximum Output, Optimal Constant

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] T.M. Jahns, G.B. Kliman & T.W. Neumann : "Interior Permanent Magnet Synchronous Motors for Adjustable Speed Drives," IEEE Transactions on Industry Application, IA-22, 738 (1986)

DOI: 10.1109/tia.1986.4504786

Google Scholar

[2] S. Morimoto, Y. Yuge, Y. Takeda, T. Hirasa : "Motor Parameters and Operating Limits of PM Motor," IEEJ D, vol. 110, No. 11, 1990 (Japan)

DOI: 10.1541/ieejias.110.1171

Google Scholar
