A Wire Feed Control System Based on Detecting Induced Electromotive Force of the Motor

Abstract:

A stable and even wire feed speed is a guarantee of good quality welding. A new wire feed system, without any speed-measuring equipment, has been designed. And the motor current of this system works in a discontinuous state. When the motor current is zero, it detects the induced electromotive force; acquires the motor speed according to the relationship between the induced electromotive force and the motor speed; calculates and compares with the given speed then changes the duty cycle of the voltage added on the motor by PWM technology, that control the motor speed. Then a stable and even wire feed speed can be achieved. Verified by testing resistance, the change rate of the wire feed speed is slightly, which proves that the new system has good mechanical properties and a stable speed. Besides, it runs reliably.

• Periodical: Advanced Materials Research (Volume 569)
• Pages: 781-784
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.569.781
• Online since: September 2012
• Authors: Zhen Yang Lu, Peng Fei Huang, Yong Gang Zhang, Shao Jun Bai
• Keywords: DC Motor (DCM), Pulse Width Modulation (PWM), Speed Feedback

References

[1] Yin Shuyan: CO2 Welding Equipment Principles and Debugging[M]. (Mechanical Industry Press, Beijing 2000) , pp.115-121.

[2] Ye Zhenzhong, Wang Yun, Yang Yu: A New CO2 Arc Welding Wire Feed Control System Used PWM[J]. Transactions of The China Welding Institution, Vol. 24(2003), pp.79-81.

[3] Zhang Yong, Shao Liangcheng: Motor Drive and Control[M]. (Mechanical Industry Press, Beijing 2001), pp.1-29.

[4] Li Zhongyong, Zhang Guangxian, Chen Maoai: Rotation Speed Control Technique by Electromotive Force Feedback Sensed From Wire Feed Motor[J]. Journal of Shandong University(Engineering Science), Vol. 32(2002). pp.105-108.
