Research for Thermal Drift of APD Gain in Distributed Temperature Sensing System Based on the Raman Back-Scattering

Abstract:

In the temperature measurement system of distributed optical fiber based on Raman back-scattering, the temperature measurement depends on a series of laser pulses in the optical fiber, which produces anti-stokes and stokes lights of Raman back-scattering at various points. By using the ratio of them, the measurement of temperature field space can be realized. But the signals that can be gained are quite weak in practice, and there are interferences of noises and external signals, therefore APD is selected (Avalance Photodiode) to amplify the weak signals. Because the gain characteristics of APD are vulnerable to the influences of temperature and bias voltage, so in this paper the experiments were carried on about the effects of temperature, bias voltage, incident power etc. on APD, and a substantive discussion was discussed.

• Periodical: Advanced Materials Research (Volume 571)
• Pages: 716-720
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.571.716
• Online since: September 2012
• Authors: Lei Sang, Jie Zhang, Xin Qun Wang
• Keywords: Gain Characteristics, Raman Back-Scattering, Thermal Drift

References

[1] Zhou Shengjun, Zhang Zhipeng: Technical implementation of distributed optical fiber temperature sensor measurement, Optical Instruments vol. 11(1997), pp.20-24.

[2] Chang Zheng, Li Zheng and Zhou Yinqing: Analysis of optimal APD avalanche gain in distributed temperature sensor system based on the Raman-Backscattering, Laser Journal vol. 1(2001), pp.17-19.

[3] Wang Qianqian, Liu Jinghai and Sun Zhiyong: Decreasing the temperature influence on avalanche photodiodes, Optical Technology vol. 3(1997), pp.7-9.

[4] Wei Kanglin, Gao Xiaoxin: Dynamic compensation for gain temperature drift of APD in the Optical fiber sensor system, Research on Optical Communications vol. 3(2007), pp.99-96.

[5] Dakin J P, Pratt D J and Bibby G W, et al: Temperature distribution measurement using Raman ratio thermometry, Fiber Optic and Laser Sensor Ⅲ vol. 566(1985), pp.249-256.

DOI: 10.1117/12.949798

[6] Samson P J: Analysis of the wavelength dependence of Raman back scattering in optic fiber thermometry, Electronic Letters vol. 26(1989), pp.163-165.

[7] Hiskett etal: Performance and design of InGaAs/InP Photondiodes for single- photon counting at 1. 55m, Applied Optics vol. 39, pp.6818-6829.

[8] Grant W N: Electron and hole ionization rates in epitaxial silicon at high electric field, Solid State Electronics vol. 16(1976), pp.1189-1203.

DOI: 10.1016/0038-1101(73)90147-0

[9] Wang Jianfeng, Zhang Zaixuan and Guo Ning: Method to improve the stability of distributed optical fiber temperature sensor, Journal of China Jiliang University vol. 11(2), pp.145-150.

[10] Li Shuibing, Wang Yu and Zhao Jiankang: Research on stability of the gain of APD in fiber Raman temperature sensor, Optical Technology vol. 9(3), pp.168-170.

[11] Wang Xinqun, He Guomin, Ding Bangqin and Huang Xin: Improvement of stability of Raman backscattering optical fiber temperature fire alarm system, Journal of University of Science And Technology of China vol. 39(4), pp.435-439, (2009).

[12] Zhou Jian: Experimental study of APD temperature drift characteristics, Piezoelectrics& Acoustooptics vol. 21(2), pp.158-160, (1999).
