Optimal Design of CCD Driving Signal Based on FLEX 10K

Abstract:

In this paper, an optimal design method for a CCD driving signal is proposed. Strict phase alignment of CCD driving signals is achieved. Through the analysis of FLEX 10K internal resources, the CCD driving pin voltage overshoots are eliminated on the basis of meeting the phase relationship. The experimental results show that the requirements for the phase of the CCD driving signals are satisfied, and the voltages on CCD pins become stabile. Therefore, CCD can be protected from damage.

• Periodical: Advanced Materials Research (Volume 571)
• Pages: 725-729
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.571.725
• Online since: September 2012
• Authors: Zhi Kuan He, Song Bo Wu, Yu Gui Zhang
• Keywords: CCD Protection, Driving Signal, Optimal Design, Phase Relationship

References

[1] Kazuya Yonemoto; Chen Rongting, Peng Meigui. Beijing: Science Press, 2006: 3-6. (In Chinese).

[2] Pan Weijun, Li Tao. Spacecraft Recovery and Remote Sensing. 2008, 29: 48-54. (In Chinese).

[3] Altera. FLEX 10K Datasheet. Version 4. 2. January, 2003: 29-31.

[4] Zhang Huiguo, Yu Zongguang. Control & Automation. 2008, 24: 188-190. (In Chinese).

[5] Qi Xinyu. Avionics Technology. 2005. 36(3): 51-54. (In Chinese).

[6] Ren Liangchao, Jin Haiming. Chinese Journal of Scientific Instrument. 2005, 26(8): 261-264. (In Chinese).
