Research on Clamping Body of the Hydraulic Climbing System of Caliper Type

Abstract:

To investigate the appropriate inclined angles, spacing between caliper and square steel satisfying the requirement of caliper switching mechanism and the appropriate tooth parameters, the relation of inclined angles of caliper and meshing force is analyzed. And the hardness parameters of caliper and square steel are also analyzed. The appropriate tooth parameters are determined based on hardness parameters of caliper and square steel and tooth parameters of caliper.

• Periodical: Advanced Materials Research (Volume 580)
• Pages: 240-243
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.580.240
• Online since: October 2012
• Authors: Hai Ying Zhou, Kai Liu, Ming Jiang
• Keywords: Caliper, Clamping Body, Finite Element Model (FEM), Hydraulic Climbing System

References

[1] CHENG Da-xian. Machinery design handbook (Version 4) [M]. Beijing: Chemical industry press, (2002).

[2] GB50017-2003. Code for design of steel structures[S]. Beijing: China Planning Press, (2003).

[3] GB/T 3811-2008. Design rules for cranes [S]. Beijing: China Planning Press, (2008).

[4] PU Liang-gui. Machinery design(Version 5)[M]. Beijing: Higher Education Press，(1995).

[5] LI Zhuang-yun. Hydraulic components and systems(Version 2)[M]. Beijing: Machinery Industry Press, (2005).

[6] ZHOU Shi-chang. The hydraulic system design (Version1)[M]. Beijing: Machinery Industry Press, (2003).
