Combined Setting Technology of the Bending Roll in Five Stands 4-High Reduction Cold Mill

Abstract:

On the foundation of taking equipment and production technology into consideration,we present a set of combined setting technology of the parameter of the strip suit to cold reduction mill of roll four and framework five。Then the parameter of the strip was controlled combined and coordinated of framework 1-5. On the one hand,it ensures the function of the force of the bending roll not cancel out mutually,and enhances the controlled effect of the force of the bending roll in the strip,on the other hand, there will not be new extra and partial shape wave under the complex effect of the force of the bending roll.Meanwhile there will not be the problem that the force of the bending roll in some parts get too high even overall loading while the other parts get get too low in the setting procedure.While improving the lifespan of the fluid cylinder, the adjusting rest of the force of the bending roll get increased. While the related technology has been adopted by field engineering, we have achieved excellent result, and there is the value for more expanding.

• Periodical: Advanced Materials Research (Volumes 602-604)
• Pages: 2045-2049
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.602-604.2045
• Online since: December 2012
• Authors: Lian Lian Zhou*, Xu Chuang Ma, Ling Kun Kong
• Keywords: Bending Roll, Cold Reduction Mill of Roll, Extra Shape Wave, Parameter of the Strip

References

[1] J.C. Lian: Calculation of Pressure of Rolling and the Boundary of the Minimum Thickness in Flat Cold-rolled Sheet. Heavy machinery, Vol. 2 (1992) No. 3, p.21.

[2] J.C. Lian and Z.Y. Duan: Research on the Extension of Rolled Piece. Steel, Vol. 19 (1984) No. 11, p.32.

[3] J.C. Lian and H.M. Liu: Control of Tthickness and Shape (Arms industry press, China 1995).

[4] L.Z. Chen: Mechanical Design Optimization Method (metallurgical industry press, China 1985).
