Study on the Online Dynamic Weighing System of Heavy Duty Apron Feeder Based on Labview

Abstract:

The heavy duty apron feeder is a mechanism for material transportation. According to the differences on test requirements and effects, the traditional sensor development test weighing system presently is adopted widely. In the design, resistance strain gauge is installed on the feeder chain plate; and the whole-armed bridge compensates temperature to test the voltage value outputted by bridge resistance gauge; based on labview software, the virtual online dynamic weighing system is developed, realizing online monitoring at full time, warning, alarming and shutdown protective operation.
