Analysis and Modeling of Error Sources for Spiral Bevel Gear Honing Machine Based on Multi-Body System Theory

Abstract:

Analyzing some main errors of NC spiral bevel gear honing machine-tool, the elements of geometric error, thermal error and force error etc., which are constructed 39 error sources of the machine by stack method. Based on multi-body system theory, using homogeneous transfer matrix(HTM) method to present six feature matrixes that includes ideal-static matrix, ideal-kinematic matrix, ideal-static translation error matrix, ideal-static rotary error matrix, non-ideal rotary motion error matrix and non-ideal translation motion error matrix, which are built between of adjacent body. Finally, the synthetic volumetric error model of six-axis honing machine-tool is established.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 1240-1243
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.1240
• Online since: December 2012
• Authors: Guo Zheng Zhang, Jiang Han, You Yu Liu
• Keywords: Error Modeling, Multi-Body System, Spiral Bevel Gear Honing Machine, Synthetic Volumetric Error Model

References

[1] Mohsen Habibi, Behrooz Arezoo, Mehrdad Vahebi Nojedeh. Tool deflection and geometrical error compensation by tool path modification, International Journal of Machine Tools ＆ Manufacture, 51(2011) pp: 439-449.

DOI: 10.1016/j.ijmachtools.2011.01.009

[2] R. Ramesh, M.A. Mannan, A.N. Poo. Error compensation in machine tool—a review part Ⅰ: geometric, cutting-force induced and fixture-dependent errors, International Journal of Machine Tools ＆ Manufacture, (2000) pp: 1235-1256.

DOI: 10.1016/s0890-6955(00)00009-2

[3] R. Ramesh, M.A. Mannan, A.N. Poo. Error compensation in machine tool—a review part Ⅱ: thermal errors, International Journal of Machine Tools ＆ Manufacture, (2000) pp: 1257-1284.

DOI: 10.1016/s0890-6955(00)00010-9

[4] WANG Xiushan, YANG Jianguo, YAN Jiayu. Synthesis error modeling of the five-axis machine tools based on multi-body system theory, Journal of Shanghai Jiao Tong University, Vol. 42, No. 5, 2008, pp: 761-769.

[5] CHEN Shuhan, YAN Hongzhi, MING Xingzu. Analysis and modeling of error of spiral bevel gear grinder based on multi-body system theory, J. Cent. South Univ. Technol. 2008, 15: 706-711.

DOI: 10.1007/s11771-008-0131-7

[6] W, Knapp. Test of three-dimension uncertainty of machine tools and measuring machines and its relation to the machine error, Ann. CIRP 1983, 32(1): 459-464.

DOI: 10.1016/s0007-8506(07)63440-4

[7] ZHANG Hongtao. Research on dynamic and real-time error compensation for two turntable five-axis NC machine tool, Dissertation of Shanghai Jiao Tong University, (2011).

[8] LIU Huanlao. Research on the geometric error measurement and error compensation of the Numerical control machine tools, Dissertation of Huazhong University of Science and Technology, (2005).
