The Study on Experimental Modal Analysis of High-Speed Rotational Shaft

Abstract:

Centering on the chuck shaft vibration problems in high speed operation of the high-speed winder, experimental modal analysis was used to identify the modal frequency and vibration modes of the chuck shaft different cross-section in the constraint, found out the sensitive point of the response signal ,and the excitation point was found by Relationship between the modal frequency and the input excitation frequency, the results show determined dominant frequency components in the response signal can provide a reliable basis for determining the vibration characteristics of the chuck shaft, analysis of distinguishing the output response signal and selecting response signal point.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 1253-1256
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.1253
• Online since: December 2012
• Authors: Jun Zhao*, Jian Chang Yuan
• Keywords: Chuck Shaft, Modal Analysis, Modal Frequency, Vibration

References

[1] Dong Lu: Study on Experimental modal analysis of the mechanical structure[D],Chong Qing:The university of Chong Qing(2007),p.1~2,in Chinese.

[2] Fangze Li,Fuqing Liu, Zheng Wang: Engineering Vibration test and analysis[M],Bei Jing: Higher Education Press(1992),p.63~64,in Chinese.

[3] Yue Kong,Cuilian Sun,Linxuan Zhang,Tianyuan Xiao: the high speed winder grooved structural dynamic optimization Based on modal analysis[J],Beijing: Department of Automation, Tsinghua University(2009),p.1~2,in Chinese.

[4] Bing,Yang: Optimization of the performance of high speed winder based on modal analysis method[D],Beijing: Tsinghua University(2007),p.1~2,in Chinese.

[5] Ward.Helen,Stefan.Lammens,Paul.Sas:ModalAnalysis Theory andExperiment[M], Beijing: Beijing Institute of Technology Press(2001),p.8~9,in Chinese.
