Multi-Band Antenna of Mobile Handset with Metal Frame for Wireless Communication

Abstract:

A new multi-band antenna of the mobile handset with a special structure for the wireless communication applications is introduced, where the intrinsic slots between metal frame and the metal ground of the handset is taken as the main structure of the handset antenna, and the slots are fed by a tapered strip and two thin open-end strips with different lengths. Good performances of the proposed antenna are obtained by using this simple structure. The measured results of the RL and efficiency are presented. The good agreement is also achieved between the measurement and the simulation. No matter in the performances of the antenna, or in the occupied area, the proposed antenna would have a valuable application in handset for the metal frame structure.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 1886-1889
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.1886
• Online since: December 2012
• Authors: Ling Bing Kong, Shun Shi Zhong
• Keywords: Efficiency, Handset Antenna, Metal Ground, Multi-Band Antenna, Slots Antenna, Wireless Communication

References

[1] Yong-Xin Guo, Zhi Ning Chen, Miniature built-in multiband antennas for mobile handsets. IEEE TRANSACTIONS ON ANTENNAS AND PROPAGATION, vol. 52, no. 8, August 2004. pp: 1936-(1944).

DOI: 10.1109/tap.2004.832375

[2] Shun-Yun Lin, Multiband folded planar monopole antenna for mobile handset, IEEE TRANSACTIONS ON ANTENNAS AND PROPAGATION, vol. 52, no. 7, July 2004. pp: 1790-1794.

DOI: 10.1109/tap.2004.831315

[3] Kin-Lu Wong, Gwo-Yun Lee, and Tzung-Wern Chiou, A low-profile planar monopole antenna for multiband operation of mobile handsets, IEEE TRANSACTIONS ON ANTENNAS AND PROPAGATION, vol. 51, no. 1, January 2003. pp: 121-125.

DOI: 10.1109/tap.2003.809044

[4] Hsuan-Wei Hsieh, Yi-Chieh Lee, Kwong-Kau Tiong, and Jwo-Shiun Sun, Design of a multiband antenna for mobile handset operations, IEEE ANTENNAS AND WIRELESS PROPAGATION LETTERS, vol. 8, 2009. pp: 200-203.

DOI: 10.1109/lawp.2008.2011655

[5] Chia-Hao Ku, Hsien-Wen Liu, and Sheng-Yu Lin, Folded dual-loop antenna for GSM/DCS/PCS/UMTS mobile handset applications, IEEE ANTENNAS AND WIRELESS PROPAGATION LETTERS, vol. 9, 2010. pp: 998-1001.

DOI: 10.1109/lawp.2010.2089037

[6] J. -S. Kuo and C. -Y. Huang, Triple-frequency planar monopole antenna for side-feed communication device on GSM/DCS/PCS operation, ELECTRON. LETT, vol. 42， no. 5. June 2006. pp: 268-270.

DOI: 10.1049/el:20064236
