The Improvement of Control System of Wind Turbine Gearbox Test Device

Abstract:

Aim at technical improve of the control system in the Wind Turbine Gearbox Test Device at a factory of Yinchuan , the design plan of the control system Based on Mitsubishi FX series PLC,FX2n-4AD,FX2n-4DA,Mitsubishi FX series Ethernet adapters and King View are put forward ,lower processor was composed by FX2N series CPU module and I/O module in that control system , moreover , centralized management and real-time monitoring of collect data are carried out through the upper processor that adopts industrial computer and King View . Through the improvement device become automation, enhance safety and capacity of product development of company.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 1866-1871
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.1866
• Online since: December 2012
• Authors: Xiao Long Li, Dan Liu, Chun Xiu Wang
• Keywords: Configuration Software, Control System, FX2N PLC, Wind Turbine Gearbox

References

[1] W.H. Liu and A.G. Xuan etc: S, GB-T 19073-2008. Wind Turbine Gearbox, In Chinese.

[2] G.B. Liu: Programmable Controller & Factory Automation, Vol. 2 (2011), p.60, In Chinese.

[3] L. Wu and X.X. Li: Coal Technology, Vol. 29(2010), p.53, In Chinese.

[4] H.P. Li: Technology and application of industrial control configuration-King View(Xi'an University of Electronic Science and Technology Publishing House, China 2011 ), In Chinese.

[5] Y.J. Ma and F.J. Qin: Industry control computer, Vol. 22(2009), p.3, In Chinese.

[6] Beijing Asiacontrol Technology Development Co. Ltd. Manual Command language of King View, In Chinese.
