A Novel Three-Port Combiner Based on Coaxial Cavity

Abstract:

In this paper, a novel three-port combiner based on coaxial cavity is presented, which consists of a band-pass filter with a transmission zero and a ultra-wideband band-stop filter, and the combiner is different to the conventional combiner based on microstrip or stripline. The design and simulated results show that the novel combiner has a good performance, which are insert loss more than -0.5dB and return loss less than -20dB between the GSM/DCS/TD band (800-2170MHz) and WLAN band (2400-2500MHz), the isolation in both bands less than -85dB, respectively. In addition, the performances of the novel combiner are demonstrated experimentally, the measured results have good agreement with simulated results.

• Periodical: Advanced Materials Research (Volumes 605-607)
• Pages: 1924-1928
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.605-607.1924
• Online since: December 2012
• Authors: Su Nan Zhang, Qiang Ye, Chang Wei Luo
• Keywords: Bandpass Filter (BPF), Bandstop Filter, Coaxial Cavity, Combiner

References

[1] Macchiarella G, Tamiazzo S: J. Trans. on MTT. Vol. 58(2010), P. 3732.

[2] Kim B, Kim Y S: J. Microwave Opt Technol Lett. Vol. 35(2002), P. 20.

[3] Hong J S, Lancaster M J: J. Trans. on MTT. Vol. 44(1996), P. (2099).

[4] Lally J F, Ciehoski R R: J. Trans. on MTT. Vol. 11(1963), P. 452.

[5] Hano K, Kohriyama H, Sawamoto K: J. Trans. on MTT. Vol. 34(1986), P. 972.

[6] Song K J, Fan Y, Zhang Y H: J. Microwave Opt Technol Lett. Vol. 48(2006), P. 2314.
